Teradek Wireless Transmitter Comparison and Buying Guide

Teradek wireless transmitters are a popular choice among videographers and filmmakers, but with so many options available, it can be overwhelming to choose the right one.

The Teradek Bolt 4K is a high-end wireless transmitter that supports 4K video at 24fps, 25fps, and 30fps.

If you're working on a budget, consider the Teradek Bolt 1000, which is a more affordable option that still offers high-quality video transmission.

Teradek wireless transmitters are known for their reliability and ease of use, making them a great choice for professionals and hobbyists alike.

For your interest: Wireless Video Cam

The Teradek Bolt 4K LT 750 is a powerful wireless transmitter, and here are some of its key features.

It can transmit lossless HD video up to 750 feet away, which is incredibly useful for capturing high-quality footage in the field.

The kit includes a wireless transmitter and receiver with bright OLED displays, making it easy to monitor and adjust settings on the fly.

The transmitter inputs video up to 4K via HDMI, which is great for capturing high-resolution footage.

The receiver outputs video via HDMI and 3G-SDI, giving you flexibility in how you choose to display your footage.

The package weight is a substantial 3.6 kg, so make sure you have a sturdy carrying case to transport it.

The box dimensions are 37.2 x 30 x 18.5 cm, which is relatively compact considering the device's capabilities.

On a similar theme: Wireless Video Transmitter for Live Streaming

The Teradek LT 750 wireless transmitter has a wireless range of 750 feet or 228.6 meters in direct line of sight.

It operates on 13 channels with a 40 MHz bandwidth, or 25 channels with a 20 MHz bandwidth. The transmitter can handle 40 MHz and 20 MHz channel capacities.

The transmitter uses frequencies between 5.19 and 5.23 GHz, and 5.75 and 5.79 GHz, without DFS. With DFS, it uses frequencies between 5.27 and 5.67 GHz. The delay is less than 0.01 ms, and the RF power is 17 dBm.

Curious to learn more? Check out: Nady U-81 Octavo Eight Discrete Uhf Channels Wireless Microphone System

The transmitter has two RP-SMA antenna ports and one HDMI input, one BNC input, and one BNC loop output. The receiver has five RP-SMA antenna ports and one HDMI output, and two BNC outputs.

The transmitter supports video formats such as 1080p 4:2:2:2 YCC, 10-bit, 23.98, 24, 25, 29.97, 30, 59.94, 60 fps, and HDMI formats such as UHD 4K 4:4:4 RGB 10-bit at 23.98, 24, 25, 29.97, 30 fps.

Here is a list of the supported video formats:

The Teradek LT 750 is a powerful wireless video transmission system, and understanding its technical specifications can help you make the most of its capabilities. It has a wireless range of 750 feet (228.6 m) in a direct line of sight.

The LT 750 supports 13 channels (40 MHz) or 25 channels (20 MHz), which can be useful in crowded environments. It also has a frequency range of 5.19 to 5.23 GHz and 5.75 to 5.79 GHz, with DFS (Dynamic Frequency Selection) frequencies available in the 5.27 to 5.67 GHz range.

One of the key features of the LT 750 is its delay, which is less than 0.01 ms. This makes it suitable for applications that require zero-delay wireless video transmission. The system also has a maximum RF power of 17 dBm and supports uncompressed wireless video compression.

Here's a summary of the LT 750's technical specifications:

The LT 750 also has a range of input and output connectors, including 1 HDMI input, 1 BNC input (3G-SDI), and 1 BNC (3G-SDI) loop output on the transmitter, and 1 HDMI output and 2 BNC output (3G-SDI) on the receiver.

Here's an interesting read: 3g Wireless

When operating in the 4.9 GHz to 6.4 GHz range, you have the option to use either licensed or unlicensed frequencies.

The key difference between licensed and unlicensed frequencies lies in the regulatory requirements and permissions needed to use them.

Licensed frequencies require explicit permission from the governing authorities, which can be a time-consuming and costly process.

For more insights, see: Anker Speaker Wireless Soundcore How to Use

Unlicensed frequencies, on the other hand, allow for immediate use without the need for permission, but may have restrictions on power output and other technical specifications.

Operating on unlicensed frequencies can be a more flexible option, but be aware that interference from other devices can be a concern.

Licensed frequencies, while more restrictive, offer a higher level of security and reliability, which is essential for critical applications.

The Teradek LT 750 wireless transmitter offers several transmission options to suit your needs. It can transmit video up to 4K30 to the Bolt 4K LT receiver, and can simultaneously transmit to up to six receivers.

The transmitter features improved metadata, range, and compatibility over its predecessors, making it a reliable choice for wireless transmission. Built-in AES-256 encryption with RSA 1024 key pairing protects your video from prying eyes.

Here are some key transmission options:

The transmitter also supports transmission of timecode and start/stop triggers from the camera, making it a convenient option for filmmakers and videographers.

The Video Sender Bolt 4K LT 750 3G-SDI/HDMI Wireless Receiver Kit is a reliable option for transmitting video signals.

This kit can receive video up to 750 feet away, making it perfect for applications where cables aren't feasible.

The kit includes a wireless receiver with a bright OLED display that allows for easy monitoring of the video signal.

The receiver outputs video via HDMI and 3G-SDI, giving you flexibility in how you choose to display the signal.

The package weight of the kit is 3.6 kg, making it a relatively lightweight option for its capabilities.

The box dimensions of the kit are 37.2 x 30 x 18.5 cm, which may be a consideration for storage or transportation.

Related reading: Wireless Hd Transmitter and Receiver Kit

The Bolt 4K LT system can transmit video up to 4K30 to the receiver and can simultaneously transmit to up to six receivers. The system features improved metadata, range, and compatibility over its predecessors.

The transmitter sends video up to 4K30 via HDMI or 3G-SDI, while the receiver outputs video via HDMI and 3G-SDI. The system also supports transmission of timecode and start/stop triggers from the camera.

Curious to learn more? Check out: Aimibo Wireless Hdmi Transmitter and Receiver

The Bolt 4K LT system uses built-in AES-256 encryption with RSA 1024 key pairing to protect your video from prying eyes. Noise reduction ensures your video is clear no matter how many devices are using the wireless spectrum.

Here are some key features of the Bolt 4K LT system:

The Bolt 4K LT system is designed to provide visually lossless transmission of 4K HDR video, superior to HEVC and H.264 solutions.

When choosing a Teradek wireless transmitter, consider the transmission distance. The Bolt 500 XT, for example, has a transmission distance of up to 500 feet.

The Bolt 500 XT also has a latency of 3ms, making it suitable for applications that require real-time video transmission.

Teradek offers several wireless transmitter options, including the Bolt 1000 XT, which has a higher transmission distance of up to 1000 feet.

The Bolt 1000 XT also has a higher power consumption than the Bolt 500 XT, requiring a separate power supply.

The Bolt 500 XT and Bolt 1000 XT both support 3G-SDI and HDMI output, making them suitable for a variety of applications.

The Bolt 500 XT is also more compact and lightweight than the Bolt 1000 XT, making it easier to transport.

Take a look at this: Aawireless - Wireless Android Auto Dongle

The Teradek Bolt 4K LT 750 3G-SDI/HDMI Wireless Transmitter and Receiver Kit is a top-notch wireless video transmission solution. It can transmit and receive lossless HD video up to 750 feet away.

This kit includes a wireless transmitter and receiver with bright OLED displays that can wirelessly receive video up to 4K30 with 10-bit 4:2:2 HDR support. The transmitter inputs video up to 4K via HDMI or video up to 1080p60 via 3G-SDI, while the receiver outputs video via HDMI and 3G-SDI.

The transmitter sends video up to 4K30 to the Bolt 4K LT receiver, and can simultaneously transmit to up to six receivers. This makes it perfect for live events or large-scale productions.

Here are some of the key features of the Bolt 4K LT system:

The Bolt 4K LT system also comes with a range of accessories, including a 2-pin Lemo D-Tap power cable, Micro-USB to USB Type-A Cable, and a transportation case.
