Iridium Communications Satellite Network and Services

Iridium Communications has a satellite network that's truly out of this world. The network consists of 66 operational satellites orbiting the Earth at an altitude of around 485 miles.

These satellites work together to provide global coverage, allowing users to make and receive calls, send data, and access other services from anywhere on the planet. The network is designed to be highly redundant, ensuring that users can stay connected even if one or more satellites experience issues.

Iridium's satellite network uses a unique constellation design, with each satellite placed in a specific orbit to ensure that at least one satellite is always visible from any point on the Earth's surface. This design allows for seamless communication services, even in areas with limited or no terrestrial connectivity.

The Iridium network is capable of supporting a wide range of services, including voice and data communications, emergency position-indicating radio beacons (EPIRBs), and even satellite-based IoT applications.

For your interest: China Communications Services

Iridium Communications has a rich history that spans over two decades. The company was launched on November 1, 1998, as Iridium SSC, and the first Iridium call was made by Vice President Al Gore to Gilbert Grosvenor, the great-grandson of Alexander Graham Bell.

The Iridium satellite constellation was initially designed to require 77 satellites for global coverage, but only 66 are actually needed. The company's logo represents the Big Dipper, and the name Iridium comes from the chemical element with atomic number 77.

Iridium's first generation constellation was developed by Iridium SSC and financed by Motorola. The satellites were deployed in 1997-2002, and the total setup cost for the first-generation fleet was approximately $5 billion. The first test telephone call was made over the network in 1998, and full global coverage was complete by 2002.

Here's a brief timeline of Iridium's major milestones:

The Iridium NEXT satellites began to be deployed into the existing constellation in January 2017, and the new system is backward-compatible with the current system, offering improved bandwidth and expected to remain operational until the 2020s.

The first generation of the Iridium satellite constellation was a massive undertaking that involved launching 77 satellites into orbit. It was developed by Iridium SSC and financed by Motorola.

The satellites were deployed between 1997 and 2002, with a total setup cost of approximately US$5 billion. This was a staggering amount of money, and it's a wonder that the project was even attempted.

The satellites were launched using a variety of rockets, including Delta II, Proton-K/DM2, Rokot/Briz-KM, and Long March 2C/SD. This was a clever move, as it helped to spread the risk and ensure that the project didn't rely too heavily on any one launch vehicle.

The first test telephone call was made over the network in 1998, and full global coverage was complete by 2002. However, the system ultimately failed to gain traction in the market, and the company went bankrupt due to insufficient revenue.

Despite the failure of the original company, the constellation continued to operate, and a new entity emerged to offer communication services to a niche market of customers. This was a smart move, as it allowed the company to adapt to changing market conditions and find new ways to generate revenue.

Curious to learn more? Check out: Telia Company

The second generation of Iridium satellites, known as Iridium-NEXT, began deploying into the existing constellation in January 2017. Iridium Communications, the successor company to Iridium SSC, ordered a total of 81 new satellites from Thales Alenia Space and Orbital ATK.

These new satellites were designed to have improved bandwidth and were backward-compatible with the current system. The existing constellation of satellites would remain operational until Iridium NEXT is fully operational.

The design for the Iridium-NEXT satellites was complete by 2010, and Thales Alenia Space was awarded the contract for $2.1 billion in June of that year. Iridium expected to spend an additional $800 million to launch the satellites and upgrade ground facilities.

SpaceX was contracted to launch all the Iridium NEXT satellites using a Falcon 9 rocket from Vandenberg Space Force Base in California. The deployment of the constellation began with the launch of the first ten Iridium NEXT satellites in January 2017.

By January 2019, a total of 75 upgraded satellites were in orbit, following the launch of an additional ten satellites on January 11, 2019.

If this caught your attention, see: Satellite Internet Constellation

Iridium Communications Inc. was formed in 2009 through the merger of Iridium Satellite LLC with a special-purpose acquisition company created by Greenhill & Co.

The company now trades on NASDAQ under the symbol "IRDM".

Iridium surpassed one million subscribers in March 2018.

Revenue for the full year 2018 was $523.0 million, with a 14% increase from the prior year.

Iridium achieved operational EBITDA of $302.0 million in 2018, up from $265.6 million the previous year.

The company manages several operations centers, including locations in Tempe, Arizona and Leesburg, Virginia, United States.

If this caught your attention, see: Russian Satellite Communications Company

The Iridium satellite constellation requires 66 active satellites in low Earth orbit to complete its constellation, with 9 spare satellites kept in-orbit to serve in case of failure. These satellites are in six polar orbital planes at a height of approximately 485 miles (780 km).

Satellites in the Iridium constellation orbit from pole to pole with an orbital period of roughly 100 minutes, providing excellent satellite visibility and service coverage, especially at the North and South poles. This design also produces "seams" where satellites in counter-rotating planes next to one another are traveling in opposite directions.

The original concept of the Iridium constellation was to have 77 satellites, which is where the name Iridium came from; the element iridium has the atomic number 77, and the satellites evoked the Bohr model image of electrons orbiting around the Earth as its nucleus.

The original Iridium constellation was a complex system that required 66 active satellites in low Earth orbit to complete its constellation.

These satellites were deployed in six polar orbital planes at a height of approximately 485 miles (780 km).

The system was launched in the late 1990s before the company went through bankruptcy.

The satellites communicated with neighboring satellites via Ka band intersatellite links to relay communications to and from ground stations.

The total setup cost for the first-generation fleet was approximately US$5 billion.

The next generation of satellite constellations is an exciting development in the field of space technology. The Iridium NEXT constellation is a prime example of this, with 81 new satellites being built to replace the existing system.

These new satellites are designed to provide improved bandwidth and are backward-compatible with the current system. The existing constellation of satellites will remain operational until Iridium NEXT is fully operational.

The Iridium NEXT satellites are being launched into space on SpaceX Falcon 9 rockets from Vandenberg Space Force Base in California. The first ten satellites were launched in January 2017, and subsequent launches have taken place regularly.

By January 2019, 75 of the upgraded satellites were in orbit, with the final ten satellites launched on January 11, 2019. The new constellation is expected to provide seamless global coverage.

The Iridium NEXT satellites are designed to be more efficient and reliable than their predecessors. They will be able to communicate with neighboring satellites via Ka band intersatellite links to relay communications to and from ground stations.

Iridium STL is a game-changer in the satellite industry. It's a commercial positioning, navigation, and timing (PNT) service developed by Satelles, which was later acquired by Iridium Communications in April 2024.

This service is based on low Earth orbit (LEO) satellites, making it unique in the industry. It's the only LEO satellite-based commercial PNT service available as of April 2024.

Take a look at this: Night Service (telephony)

Iridium Communications Inc. provides mobile voice and data communications services and products to businesses, governments, and consumers worldwide.

The company offers a range of services, including mobile satellite communications for land mobile end users and aviation sectors.

Iridium Communications also provides broadband terminals, embedded devices, and handsets for merchant shipping, fishing, leisure and research vessels, and specialized watercraft.

In addition to these services, Iridium Communications offers satellite-based IoT services, hosted payload and other data services, and personnel tracking devices.

See what others are reading: Data Communication

Air safety communications are a crucial aspect of ensuring the secure and efficient movement of aircraft. The Federal Aviation Administration (FAA) issued a ruling in July 2011 that approves the use of Iridium for Future Air Navigation System (FANS) data links. This allows satellite data links with air-traffic control for aircraft flying in the FANS environment. The FAA's ruling includes areas not served by Inmarsat, such as polar routes above or below 70 degrees latitude.

Take a look at this: European Data Relay System

Iridium Communications Inc. offers a range of telecom communication services that cater to various industries and users.

The company provides mobile voice and data communications services to businesses, governments, and consumers worldwide.

Iridium's services include mobile satellite communications for land mobile end users and aviation sectors.

In 2011, the FAA approved the use of Iridium for Future Air Navigation System (FANS) data links, enabling satellite data links with air-traffic control.

Iridium Communications Inc. offers broadband terminals, embedded devices, and handsets for merchant shipping, fishing, leisure, and research vessels.

The company also provides satellite-based IoT services, hosted payload and other data services, and personnel tracking devices.

Asset tracking devices for equipment, vehicles, and aircrafts are also part of Iridium's services portfolio.

In January 2020, the Iridium constellation was certified for use in the Global Maritime Distress and Safety System (GMDSS), ending a monopoly held by Inmarsat since 1999.

Iridium's services are sold to commercial end users through a wholesale distribution network that includes service providers, value-added resellers, and manufacturers.

Take a look at this: Rich Communication Services

The Iridium system uses three different handoff types. As a satellite travels over the ground location, calls are handed to adjacent spot-beams, which occurs approximately every fifty seconds.

A satellite only stays in view for seven minutes at the equator. This short window of time means that handoffs need to happen quickly and efficiently to maintain a stable connection.

When the satellite disappears from view, an attempt is made to hand the call to another satellite. If no other satellite is in view, the connection is dropped.

The satellites are also able to transfer mobile units to different channels and time slots within the same spot beam. This allows for a seamless transition of calls, even when the signal is strong.

Discover more: When Communicating It's Important to

Iridium Communications offers a range of products and solutions for various applications.

One notable product is the Iridium 9601, a short burst data modem that supports only SBD for IoT services and does not use a SIM card. It's an OEM module designed for integration into applications that only use the Iridium Short Burst Data Service.

The company also offers smaller and more compact versions of this modem, such as the Iridium 9602 and Iridium 9603, which are designed for specific use cases.

Iridium Communications is also launching Project Stardust, a 3GPP standard-based satellite-to-cellphone service that will co-exist with the company's existing proprietary solution on its global low-earth orbit satellite network.

Iridium offers a range of satellite handsets to suit different needs.

The Iridium 9555 is one of the handsets available, offering mobile-satellite service. It's a reliable option for staying connected in remote areas.

The Extreme PTT is another option, designed for use in extreme environments. It's a rugged and durable choice for those who need it.

Iridium handsets can also be contacted using email, SMS, and a web-based interface. This makes it easy to stay in touch with others, even when you're far from civilization.

Here are some of the satellite constellations and networks that Iridium partners with:

One Way Pagers are devices that can receive messages sent in the form of SMS.

The Motorola 9501 and Kyocera SP-66K are examples of one-way pagers made for the Iridium network.

Messages are delivered to pre-selected "MDAs" which cover a certain geographic area.

Three of these MDAs may be selected on a web-based portal or updated automatically if the paging service is bound to an Iridium phone.

Each country has its own MDA based on its country code; some of the larger countries are divided into several MDAs, while separate MDAs exist for sections of ocean and common aeronautic routes.

On a similar theme: Eutelsat 115 West B

Standalone transceiver units are designed for remote data-logging applications, such as data collection satellites. These devices can communicate with their base via Iridium satellites.

Some types of buoys, like those used for the tsunami warning system, use Iridium satellites to send short burst data (SBD) messages to their base at specified intervals.

The Iridium Core 9523 is a modular transceiver released in 2012, similar to the 9522B. It's smaller than the 9522A and has similar features, including support for Circuit-Switched Data (CSD).

The Iridium 9522B is a transceiver released in late 2008, and it's smaller than the 9522A. It supports both SBD and CSD.

The Iridium 9522A is based on the 9522, and some variants have built-in GPS and autonomous reporting functions. It supports SBD.

Motorola 9522 is the last Motorola transceiver, and it supports outgoing SMS but no SBD. It's designed for use in vehicles with an accompanying handset.

Motorola 9520 is the original transceiver module, and it doesn't support outgoing SMS or SBD. It's designed for use in vehicles with an accompanying handset.

Here's a list of some popular standalone transceiver units:

Qualcomm and Iridium announced an agreement in 2023 to bring two-way satellite messaging service to Android smartphones through Snapdragon Satellite.

Smartphone manufacturers have shown a preference for standards-based solutions over proprietary ones, which is why Qualcomm and Iridium are now collaborating on standards-based solutions.

In 2024, Iridium introduced Project Stardust, a 3GPP standard-based satellite-to-cellphone service focusing on messaging, emergency communications, and IoT.

The solution will be supported using a version of the NB-IoT standard for 5G non-terrestrial networks (NTN) and is scheduled for launch in 2026.

Project Stardust won't replace Iridium's proprietary solution for voice and high-speed data, but will instead co-exist with it on the company's existing global low-earth orbit satellite network.

Related reading: Project Kuiper

Iridium Communications is a company that doesn't work alone. It's a founding member of the Hosted Payload Alliance (HPA), a satellite industry program that brings together satellite operators, manufacturers, and other interested parties.

The HPA is a significant partnership for Iridium, offering a platform for collaboration and innovation in the satellite industry.

Iridium Communications has a significant amount of debt, with a Total Debt/Equity ratio of 381.99% as of the last reported quarter.

Their cash flow situation is also noteworthy, with a Total Cash balance of $79.31 million and a Levered Free Cash Flow of $284.89 million over the past year.

Here are some key financial metrics for Iridium Communications:

In terms of profitability, Iridium Communications has a Profit Margin of 13.20% and a Return on Equity of 17.96% over the past year.

Their revenue has been steadily increasing, reaching $857.55 million over the past year, with a Net Income Available to Common of $113.17 million.

Iridium Communications have gateways located in Iridium satellites, Iridium Communications, Communications satellite constellations, Satellite telephony, and Satellites in low Earth orbit.

The Iridium network uses a TDMA and FDMA based system, operating on the L-band spectrum between 1,616 and 1,626.5 MHz.

Iridium exclusively controls 7.775 MHz of this spectrum, and shares a further 0.95 MHz. This shared spectrum is used by radio astronomers to observe hydroxyl emissions.

Curious to learn more? Check out: Telstar 1

External antennas used with Iridium handheld phones, data modems, and SBD terminals typically have a 3 dB gain, 50 ohms impedance, and RHCP (right hand circular polarization).

Iridium antennas can be used for both Iridium and GPS reception, thanks to their proximity in frequency.

The type of modulation used by Iridium is normally DE-QPSK, although DE-BPSK is used on the uplink for acquisition and synchronization.

Each time slot is 8.28 milliseconds long, and sits in a 90 milliseconds frame. This frame is divided into four upstream slots and four downstream slots, using time-division multiplexing.

Channels are spaced at 41.666 kHz, with each channel occupying a bandwidth of 31.5 kHz, allowing for Doppler shifts.

Here's a breakdown of the Iridium spectrum usage:

In 2010, the shared spectrum was reduced from 2.625 MHz, indicating a change in Iridium's spectrum allocation.

The Iridium system's patents are a significant part of its history. U.S. Patents 5,410,728 and 5,604,920 cover the field of satellite communications.

A unique perspective: Thaicom 5

Motorola was instrumental in generating several hundred patents to protect the technology in the Iridium system. The company's manufacturing initiatives played a crucial role in the system's technical success.

The engineer who set up the automated factory for Apple's Macintosh was a key hire for Motorola. He created the technology to mass-produce satellites on a gimbal, reducing production time from months or years to just weeks.

At its peak, Motorola produced a new satellite every 4.3 days. This remarkable pace was achieved during the launch campaign in 1997 and 1998, with a lead-time of just 21 days for a single satellite.

Iridium Communications has had its fair share of defunct satellites. The first Iridium satellite, Iridium 1, was launched in 1997 but failed to reach orbit.

A total of 66 Iridium satellites were launched between 1997 and 1999, but many of them suffered from technical issues and were eventually decommissioned.

Iridium 33, one of the original 66 satellites, was the first to be decommissioned in 1999.

The Iridium system was plagued by problems, including a high failure rate and a lack of adequate funding.

A unique perspective: How Many Spacex Satellites Are There

Iridium OpenPort is a broadband satellite voice and data communications system used by maritime vessels for crew calling and email services. It operates at a relatively slow speed of 2.2 to 3.8 kbit/s, requiring aggressive voice compression and decompression algorithms.

Latency for data connections averages 1800 ms round-trip, with a mode of 1300 to 1400 ms and a minimum around 980 ms. This can be a challenge for users, especially those who are not accustomed to delayed communication.

Iridium Certus, on the other hand, offers a much faster service with up to 704 Kbps of bandwidth, making it suitable for a wide range of applications, including maritime, aviation, and IoT.

Related reading: Voice Frequency

Certus is a globally available satellite broadband service that offers up to 704 Kbps of bandwidth. This means you can stay connected and productive from anywhere in the world, whether you're at sea, in the air, or on land.

The service is provided by Iridium NEXT and is designed for various applications, including maritime, aviation, land mobile, government, and IoT.

Terminals for the service are provided by reputable companies like Cobham, Intellian Technologies, and Thales.

Check this out: Communication Service for the Deaf

OpenPort is a broadband satellite voice and data communications system used by maritime vessels. It's used for crew calling and email services on ships like merchant fleets, government and navy vessels, fishing fleets, and personal yachts.

Iridium OpenPort operates at a relatively slow speed of 2.2 to 3.8 kbit/s. This requires very aggressive voice compression and decompression algorithms to make communication work.

The speed may seem slow, but it's comparable to other communication systems like AMR used in 3G phones, which requires a minimum of 4.75 kbit/s.

Latency for data connections averages around 1800 ms round-trip, with a mode of 1300 to 1400 ms and a minimum of 980 ms.

If this caught your attention, see: Voice Phishing

Iridium STL is a game-changer in the world of satellite technology, providing a commercial positioning, navigation, and timing (PNT) service that's unlike anything else out there.

Developed by Satelles, which was later acquired by Iridium Communications in April 2024, it's the only LEO satellite-based PNT service currently available.

Worth a look: Internet Telephony Service Provider

The orbital velocity of Iridium satellites is a whopping 27,000 km/h, or 17,000 mph, which is incredibly fast.

This speed allows for seamless communication between satellites via Ka band inter-satellite links, which are used for navigation and timing purposes.

Each satellite can have up to four inter-satellite links, connecting it to neighboring satellites in the same or adjacent planes.

The constellation of 66 active satellites has six orbital planes spaced 30° apart, with 11 satellites in each plane, providing excellent coverage and service availability.

Iridium's over-the-pole orbital design means that satellites can provide service coverage, especially at the North and South poles, where it's often needed most.

The orbital period of these satellites is roughly 100 minutes, which is quite short compared to other satellite systems.

This unique design also produces "seams" where satellites in counter-rotating planes next to one another are traveling in opposite directions, requiring rapid inter-satellite link hand-offs.

To mitigate this issue, Iridium only supports inter-satellite links between satellites orbiting in the same direction.

The original concept for Iridium was to have 77 satellites, which is where the name "Iridium" came from – the element iridium has the atomic number 77.
