White spaces (radio) Technology Improves Urban and Rural Connectivity

White spaces (radio) technology has revolutionized the way we connect in urban and rural areas. It's a game-changer for communities that struggle with poor internet access.

The technology uses unused TV channels to provide a broadband connection, which can reach speeds of up to 1 Gbps. This is particularly beneficial for rural areas where traditional internet infrastructure is often lacking.

In fact, white spaces technology has been shown to be 10 times faster than traditional wireless networks in some areas. This makes it an attractive option for communities that need fast and reliable internet access.

By leveraging unused TV channels, white spaces technology can provide a cost-effective solution for bridging the digital divide.

For your interest: Florida Rural Broadband Alliance

White space, also known as TV white space, refers to the unused radio frequency spectrum that was initially set aside for television broadcasting. This spectrum is located between TV channels and is now open to various wireless communication applications.

Check this out: Direct-sequence Spread Spectrum

The term "white space" comes from the fact that these frequencies were left unoccupied to avoid interference between TV stations. With the switch from analog to digital television, these white areas are now available for use.

TV white space is found in the UHF spectrum's lower frequency ranges, typically between 470 MHz and 698 MHz. This range allows signals to travel farther and pass through obstacles like walls and buildings more successfully.

The propagation characteristics of lower frequencies make TV white space an attractive option for wireless applications that require a broad transmission range. TV white space can cover several kilometers, reducing the need for multiple base stations or repeaters.

TV white space signals can traverse walls, trees, and other physical barriers, making them suitable for deployment in rural, suburban, and urban areas alike. Operating in less congested spectrum bands ensures stable and interference-free connections, even in dense environments.

Here are some key benefits of TV white space:

White spaces (radio) technology offers numerous benefits and applications. TV white space technology can provide rural broadband internet access by extending coverage, using unlicensed spectrum, and leveraging existing infrastructure.

TVWS antennas can be used to bridge coverage gaps in urban and suburban areas where cellular or Wi-Fi signals are spotty or unreliable. This technology has been used to connect rural neighborhoods and even urban housing schemes that previously lacked internet access.

TVWS antennas create reliable communication networks for emergency responders and those affected during emergencies, natural disasters, or major events. This is especially useful for disaster relief efforts, as seen in the typhoon that hit the central Philippines.

TVWS antennas can be used to connect IoT devices in industries such as smart cities, agriculture, and environmental monitoring. This enables applications like smart farming, wildlife tracking, air quality monitoring, and traffic control.

The benefits of TVWS technology include:

TVWS technology can also be used to optimize spectrum consumption in locations with numerous users or devices, such as industrial or congested urban settings.

In urban areas, white spaces can be found in lower frequency bands, such as UHF and VHF, which provide better coverage and can penetrate obstacles like walls and trees.

This extended range is advantageous for planners wanting to create wireless communication networks in urban areas, where numerous wireless networks coexist in close proximity.

Signals in this frequency range can reduce interference, which is a significant risk in densely populated urban areas.

Reducing interference directly translates to enhanced connectivity for users, undoubtedly improving the quality of service.

In Europe, white spaces are allocated in the frequency range of 470-790 MHz, while in the USA, they are allocated in the range of 470-698 MHz.

Allocating white spaces can help mitigate the risk of interference, making it easier for telecommunications companies to provide reliable services.

As the demand for cleaner and more reliable spectrum continues to rise, regulatory authorities can benefit from increased competition for frequency licenses, resulting in higher costs for telecommunications companies and wireless internet service providers.

Explore further: Wifi Rf Frequency

Rural broadband internet access is a significant challenge in underserved areas, but TV white space technology offers a potential solution.

TVWS technology extends coverage, uses unlicensed spectrum, and leverages existing infrastructure to provide internet connectivity in rural areas.

This technology has been instrumental in providing connectivity to remote and unconnected locations, and it requires less infrastructure than traditional cellular networks, reducing costs.

Using white spaces to provide broadband services in rural areas has several benefits, including reduced costs, increased connectivity, and socio-economic benefits such as improved access to education, healthcare, and advanced agricultural practices.

TVWS antennas create reliable communication networks for emergency responders and those affected during emergencies, natural disasters, or major events.

By identifying white spaces in specific geographic areas, regulatory authorities can provide and license additional frequency resources, allowing rural areas to accommodate more IoT devices by providing more bandwidth and reducing congestion.

TVWS has a wider coverage than cellular-WLAN because of its higher penetrating feature and longer transmission range, which enables seamless wireless service.

Here's an interesting read: Affordable Connectivity Program

TVWS provides cost-effective coverage for low-density and underserved areas, while cellular networks require substantial infrastructure investment.

TVWS has a range of up to 24.8 miles, and it uses very little power between 20 and 100 watts, depending on the vendor, the device, and the length of the antenna, among other factors.

Here are some key differences between TVWS and Wi-Fi:

In emergency situations, traditional communication channels can become congested due to an overload in traffic.

Emergency services can use white spaces to provide additional bandwidth and serve as reliable communication backups.

White space devices can automatically detect and access available frequencies, allowing for resilient communication even when other channels are compromised.

This means that emergency communications using white spaces can reach further distances to more remote areas.

As signals in white spaces can travel longer distances than signals in higher bands, they can be particularly useful in areas where traditional communication methods may not be effective.

Suggestion: Emergency Radio

TVWS antennas are designed to operate in the TV White Space frequency band, which is mostly between 470 and 698 MHz. They provide dependable, strong connections over long distances while preserving high-quality communications.

There are various types of TVWS antennas, including Yagi-Uda antennas, which are directional antennas with a high gain suitable for long-distance point-to-point connections. Omnidirectional fiberglass TVWS antennas, on the other hand, provide 360-degree coverage and are often used in urban areas with multiple TVWS base stations.

TVWS antennas require consideration of frequency range and bandwidth support to ensure peak performance and compliance with regulations. The transmit power of the antenna, frequency being used, topography, and environmental obstructions can affect the range of TVWS antennas.

TVWS sector antennas optimize spectrum consumption in locations with numerous users or devices by dividing coverage into discrete sectors. They work especially well in industrial or congested urban settings.

TVWS antennas come with various connectors, such as 1x TNC Connector and 24" coaxial pig tails with N-male connectors, to ensure smooth integration with communication systems and devices.

Expand your knowledge: Wifi 7 Devices List

Here are some key advantages of TVWS antennas:

There are several types of TVWS antennas, each designed to meet specific needs and applications.

Yagi antennas are directional antennas with a high gain that work well for long-distance point-to-point connections. They're often used in remote locations where a long-distance TVWS signal transmission is required.

Omnidirectional fiberglass TVWS antennas provide 360-degree coverage, radiating the signal in all directions. They're typically used in urban areas with multiple TVWS base stations, where the signal needs to reach devices in various directions.

Directional panel TVWS antennas offer a greater beamwidth than Yagi antennas but are still directional. They're used in situations where both multidirectional and long-distance coverage are required, such as in suburban areas with multiple TVWS base stations.

Here are some key characteristics of each type of antenna:

Google is working on a spectrum database to facilitate spectrum sharing, which is a way for different devices to use the same frequency band without interfering with each other.

Spectrum sharing is a complex process, but essentially it's about finding ways for multiple devices to use the same frequency band without causing harmful interference.

The purpose of a spectrum database is to keep track of which devices are using which frequency bands and where they are located. This information helps prevent interference and ensures that devices are using the spectrum efficiently.

To ensure that spectrum sharing doesn't cause harmful interference, the database checks for potential conflicts and alerts users if there are any issues.

The current status of the database is that it's being developed by Google, but more information is not yet available.

If you want to learn more about the spectrum database, you can check out the Google website or look for updates from industry experts.

Here are the key questions about the spectrum database answered:

Real-world examples of white space technology in action are plentiful. In underprivileged areas, the implementation of TVWS for internet connection has resulted in notable advancements in economic growth, healthcare, and education.

The Philippines Rural Connectivity Project is a notable example, where TVWS has improved connectivity and offered social services to the population. Google's Project Loon, when applied to TVWS, would essentially utilize its network of high-altitude balloons to deliver internet connectivity to remote areas.

TVWS has also been used to create smart spaces, such as office buildings and museums, by providing wireless connectivity and automated systems. This technology relies on IoT devices, which can be affected by network congestion caused by their thirst for bandwidth.

Regulatory barriers, equipment costs, and spectrum sharing are significant challenges to widespread adoption of TVWS. Spectrum regulations vary widely across regions, presenting challenges for widespread adoption.

In the Philippines, numerous initiatives are underway to leverage technology and the Internet to provide services and education to those who are rarely connected to the Internet. TV white space has been adopted by the nation to improve connectivity and offer social services to the population.

In 2011, the Yurok Tribe in Humboldt County, California began white space trials with telecommunications equipment provider Carlson Wireless of Arcata, California. TV Band Service, made up of private investors, has put up cameras in parks, and along highways to show traffic.

TV Band had an 18-month experimental license, which allowed them to test the technology without interference issues. The smart city network in Wilmington, North Carolina, uses the white spaces made available by the end of analog TV to provide wireless connectivity and automated systems.

You might enjoy: Citizens Band Radio

In Kenya, commercial deployments of TVWS are planned for 2022, following multiple tests and trials that have been conducted.

The first trial was conducted between 2013 and 2015 under the Mawingu project, led by Microsoft East Africa through the Microsoft 4Afrika initiative.

TVWS trials in Kenya have been authorized by the Communications Authority (CA), which issued a trial authorization to Microsoft East Africa Limited in August 2013.

The Mawingu project led to the establishment of Mawingu Networks as an ISP and was provided an extension for another year between November 2014 to December 2015.

In November 2016, CA permitted another TVWS trial countrywide by the Broadcast Signal Distributors – Signet and PANG.

All pilots conducted in Kenya (until 2020) have been successful and did not cause any interference to the incumbents.

The Mawingu project connected some schools, hospitals, a library and the Red Cross leveraging TVWS technology in the rural Laikipia and Nyeri counties.

For your interest: Net Neutrality Regulation 2015

TVWS networks have demonstrated technical viability with PtMP coverage of about 14-20 km achievable with TVWS base stations transmitting at 2.5 Watts.

The allowed transmission power in the regulations is 42 dBm (4W) which can practically cover a range of 30 km with a reasonable CPE antenna gain of about 11dB.

Internet speeds released from the network range from 16 – 20 Mbps on a single 8 MHz channel.

Suggestion: Does Wifi 6 Have Better Range

White spaces devices are designed to detect unused areas of airwaves, such as those reserved for analog television, and utilize them for White Space Internet signals.

Early ideas proposed using GNSS receivers and programming each WSD with a database of all TV stations in an area, but this would not have avoided other non-stationary or unlicensed users in the area.

Professional wireless microphones have used white space for decades, long before the introduction of white space devices.

A different take: Storage Area Network

TV white space (TVWS) and Wi-Fi are both wireless connections, but they operate on different frequency ranges. TVWS uses the 470 MHz to 698 MHz ranges, while Wi-Fi uses the 2.4 and 5 GHz frequencies.

TVWS has a significantly greater range than Wi-Fi, making it suitable for wide-area applications. This is because TVWS operates in underutilized spectrum bands, reducing interference and allowing for longer transmission ranges. TVWS can cover up to 24.8 miles, as claimed by Carlson Wireless, one of the three major producers of TV white space.

TVWS also offers cost-effective coverage for low-density and underserved areas, unlike cellular networks which require substantial infrastructure investment. This makes TVWS a great option for rural areas where Wi-Fi may not be as effective.

TVWS and Wi-Fi have different strengths and weaknesses. TVWS excels in outdoor, long-range connectivity, while Wi-Fi is better suited for indoor, high-density scenarios. TVWS also leverages unlicensed spectrum, reducing operational costs and regulatory barriers.

Here are the key differences between TVWS and Wi-Fi:

Devices that use white spaces left by the termination of analog TV to provide wireless broadband Internet access are called white-spaces devices (WSDs).

Additional reading: Eero Wifi 6e

These devices are designed to detect the presence of existing but unused areas of airwaves, such as those reserved for analog television, and utilize them for White Space Internet signals.

Early ideas proposed using GNSS receivers and programming each WSD with a database of all TV stations in an area, but this would not have avoided other non-stationary or unlicensed users in the area.

Professional wireless microphones have used white space for decades, even before the introduction of white space devices.

In 2017, Microsoft researched using small cell LTE eNodeB's operating in TV White Space to provide cost-effective broadband to affordable housing residents.

South Korea has been a leader in implementing TV white space technologies to expand rural internet access and enhance disaster communications.

The government has supported the use of these technologies, and in 2020, a portable Wi-Fi device based on TVWS was selected as an official R&D Innovation Product.

Innonet Co., Ltd. developed this device and has since used its technologies internationally, including deployments in South Africa, Tanzania, and Colombia.

Google partnered with the Independent Communications Authority of South Africa (ICASA) to deliver wireless access to 10 schools in South Africa through 3 base stations.

The trial took place over 10 months and showed promising results, paving the way for further development of TV white space technologies in the country.

ICASA subsequently issued regulations on the use of television white spaces in 2018, and temporary TV white space spectrum licenses were issued in April 2020 to Mthinthe Communications, Levin Global & Morai Solutions.

In 2023, Innonet Co., Ltd. partnered with the Council for Scientific and Industrial Research (CSIR) to provide 24 TV white space communication units to improve internet connectivity in rural areas of South Africa.

Ofcom, the licensing body of spectrum in the UK, has made white-space free to use, allowing for the development of white space Wi-Fi technologies.

A large commercial test of white space Wi-Fi was conducted in Cambridge, England in 2011, demonstrating the potential of these technologies to provide broadband IP connectivity.

Consider reading: Use 5g Standalone Network

The test showed that white space Wi-Fi can provide reliable connections even in challenging radio propagation environments.

Full power analog television broadcasts ceased operating in the United States on June 12, 2009, allowing for the use of the freed-up spectrum for wireless broadband services.

The White Spaces Coalition has been working to develop wireless broadband services using this spectrum, with the goal of providing affordable internet access to consumers.

Theatrical producers and sports franchises initially opposed the use of white space technologies, citing concerns about interference with their own transmissions.

However, the FCC ultimately rejected their arguments, stating that sufficient testing had been done to minimize potential interference.

Additional reading: Over-the-top Media Services in India

Regulation and laws surrounding white spaces (radio) are complex and have undergone significant changes over the years. The FCC's decision to approve unlicensed use of white space in 2008 was a major milestone.

However, this approval came with strict requirements, including the need for devices to consult an FCC-mandated database to determine available channels and to monitor the spectrum locally every minute to confirm no legacy wireless microphones or other emitters are present.

On a similar theme: Fcc Internet Net Neutrality

Devices must also adhere to strict emission rules, which effectively make the new spectrum unusable for Wi-Fi technologies. The FCC released a Memorandum Opinion and Order in 2010, which determined the final rules for the use of white space for unlicensed wireless devices.

Some of the key regulatory challenges include ensuring harmonious coexistence with licensed users, which requires careful planning and coordination. This is especially true in regions where spectrum regulations vary widely.

Relying on low-cost handheld spectrum analyzer solutions is not ideal due to their limited frequency range, low accuracy, and lack of real-time signal identification and interference mitigation.

Regulatory authorities must strictly design and monitor programs to ensure licensed transmissions are not degraded.

Low-cost analyzers may have limited data logging and documentation capabilities, making it challenging to record and analyze collected data for reporting and decision-making.

To ensure precise measurements, highly sensitive RF receivers used in conjunction with real-time monitoring software can provide a powerful toolset for optimizing white space use while ensuring regulatory compliance and maintaining the quality of wireless communications.

Take a look at this: High-capacity Data Radio

The FCC's Office of Engineering and Technology released a report in 2008 that concluded prototype TV-band white spaces devices had met the burden of proof of concept in detecting and avoiding legacy transmissions.

However, none of the tested devices adequately detected wireless microphone signals in the presence of a digital TV transmitter on an adjacent channel.

Devices must both consult an FCC-mandated database to determine which channels are available for use at a given location, and must also monitor the spectrum locally once every minute to confirm that no legacy wireless microphones, video assist devices or other emitters are present.

In 2009, the National Association of Broadcasters (NAB) and the Association for Maximum Service Television (MSTV) asked a Federal court to shut down the FCC's authorization of white space wireless devices.

The lawsuit claimed that portable, unlicensed personal devices operating in the same band as TV broadcasts have been proven to cause interference despite FCC tests to the contrary.

The plaintiffs, NAB and MSTV, alleged that the FCC's decision to allow white space personal devices would have a direct adverse impact on their members.

The case was filed in a United States Court of Appeals for the District of Columbia Circuit.

A Motion to Govern the case was due to be considered on February 7, 2011.

In May 2012, the NAB announced it was dropping its court challenge of rules that allow the unlicensed use of empty airwaves between existing broadcast channels.
