Remote Radio Head Advantages and Disadvantages Explained

Remote radio heads offer a range of advantages, including improved flexibility and scalability. This is because they can be easily installed and upgraded without disrupting the entire system.

One major benefit is reduced installation costs. By not having to run cables to the antenna, costs are significantly lower. This is especially true for large-scale installations.

In addition to cost savings, remote radio heads also provide increased safety. With no need for personnel to climb towers or navigate hazardous terrain, the risk of injury is greatly reduced.

They can also be easily maintained and repaired, with remote access allowing technicians to diagnose and fix issues without on-site visits.

Fibre to the Antenna (FTTA) allows for lower power requirements and a reduced base station footprint compared to conventional tower sites. This architecture promotes the separation of power and signal components from the base station and relocates them to the top of the tower mast in a Remote Radio Head (RRH).

Explore further: 5/8 Wave Cb Base Station Antenna

Using FTTA enables distributed antenna sites, which is a significant improvement over traditional tower sites. FTTA also eliminates the need for digging and leased circuits from telcos.

Wireless to the Antenna (WTTA) uses wireless links instead of fibre to connect the Remote Radio Head (RRH). This approach allows for quick installation, taking hours rather than days, weeks, or months, and avoids disrupting busy city streets.

If this caught your attention, see: Wireless Access Point

Fourth generation (4G) and beyond infrastructure deployments will include the implementation of Fiber to the Antenna (FTTA) architecture. FTTA architecture has enabled lower power requirements, distributed antenna sites, and a reduced base station footprint than conventional tower sites.

The Telcordia industry standard GR-3177 establishes generic requirements for Fiber to the Antenna (FTTA) protection. RRHs located on cell towers will require Surge Protective Devices (SPDs) to protect the system from lightning strikes and induced power surges.

There is also a change in electrical overstress exposure due to the relocation of the equipment from the base station to the top of the mast.

Curious to learn more? Check out: Base Station Subsystem

Fibre to the Antenna (FTTA) has enabled lower power requirements, which is a significant advantage in infrastructure deployments.

The use of FTTA architecture has led to the implementation of distributed antenna sites, allowing for a reduced base station footprint compared to conventional tower sites.

This separation of power and signal components from the base station has made it possible to relocate them to the top of the tower mast in a Remote Radio Head (RRH).

Worth a look: Magnetic Base Cb Radio Antenna

Wireless to the Antenna (WTTA) is a game-changer for 4G/LTE networks, allowing for quick installation times of just hours, rather than days, weeks, or months.

Using Wireless (Microwave, Millimeter Wave, Free Space Optics) links instead of fibre, Remote Radio Heads (RRHs) can be connected without the need for fibre optics.

This approach avoids the hassle of digging trenches, leased circuits from telcos, dark fibre, or way-leaves for disrupting busy city streets.

Installation times are significantly reduced, making it possible to realise 4G/LTE networks much faster.

Vendors like Wireless Excellence are pioneering WTTA with their CableFree MMW and FSO product lines.

Readers also liked: T-Mobile 4G LTE CellSpot

The remote radio head (RRH) is a crucial component of modern wireless communication systems. It contains the base station's RF circuitry, along with analogue-to-digital or digital-to-analogue converters and up/down converters.

The RRH is connected to the baseband unit (BBU) via a fibre optical cable, which uses the common public radio interface (CPRI) protocol. This is because fibre optic cables have less loss and are cheaper compared to RF coaxial cables, especially at high bit rates.

The RRH is made up of an RF transmitter chain and an RF receiver chain, which includes components such as ADCs, DACs, mixers, PA, LNA, etc. In the transmitter section, the RRH converts digital signals to RF and amplifies the signal to the desired power level.

In the receiver section, the RRH receives the desired band of signal from the antenna and amplifies it. The RF signal is then converted back to a digital signal in the receiver chain.

A unique perspective: Shortwave Radio Receiver

Here are the three different information flows that are multiplexed over the digital interface of the RRH:

The RRH interfaces support layer-1 and layer-2 functionalities, with layer-1 supporting electrical interface, optical interface, and TDM of different data types and low-level signaling.

Recommended read: Radio Interface Layer

Remote radio head technology offers numerous benefits that make it an attractive solution for wireless communication systems. By locating radio heads closer to the antennas, signal loss due to RF coaxial cables can be eliminated, resulting in improved signal quality.

RRH technology also enables easier installation of antennas in various locations, including hard-to-reach areas and densely populated urban regions. This flexibility helps to expand coverage and increase network capacity. In addition, radio heads are placed closer to the RF antennas, hence less power is required to transmit the signals due to low signal loss.

RRH technology can be applied to various wireless communication systems, particularly in cellular networks. The key applications include 5G NR networks, LTE networks, Distributed Antenna Systems (DASs), cellular network densification, fixed wireless access, Internet of Things (IoT), Railway and Transportation systems, Public safety networks, and rural broadband.

Here are some of the key applications of RRH technology:

The benefits of Remote Radio Head (RRH) technology are numerous and significant. By locating radio heads closer to the antennas, signal loss is minimized compared to traditional base stations, resulting in improved signal quality and better overall network performance.

RRH allows for easier installation of antennas in various locations, including hard-to-reach areas and densely populated urban regions. This flexibility helps to expand coverage and increase network capacity.

Radio heads are placed closer to the RF antennas, hence less power is required to transmit the signals due to low signal loss. This reduces energy consumption and operational costs.

Centralized baseband processing allows efficient resource allocation and interference management, leading to improved network performance and reduction in co-channel interference.

RRH technology enables easier upgrades and modifications to the Baseband Unit (BBU), making it future-proof against technological advancements and changes in network standards. This scalability and flexibility are essential for network infrastructure in congested urban areas.

Here are some key benefits of RRH at a glance:

Remote Radio Head technology has a wide range of applications in various wireless communication systems.

One of the key areas where RRH technology is applied is in cellular networks, particularly in 5G NR networks and LTE networks.

RRH technology is also used in Distributed Antenna Systems (DASs) to enhance indoor coverage and capacity.

In addition to cellular networks, RRH technology is used in fixed wireless access and Internet of Things (IoT) applications.

RRH technology is also used in Railway and Transportation systems, Public safety networks, and rural broadband initiatives.

Temporary events such as sports, concerts, and fairs also use RRH technology to provide reliable and high-quality wireless communication services.

Broaden your view: Cellular Network

Remote radio head technology has its limitations, and it's essential to consider these drawbacks before implementation. High-speed fiber optic cables are required between the BBU and RRHs, which can be costly, especially in remote or challenging terrains.

One of the significant disadvantages of RRH is the need for skilled personnel for on-site troubleshooting and repairs, even with remote management solutions. This can be a challenge in areas where specialized labor is scarce.

The distance between the BBU and radio units is crucial for maintaining optimal signal quality. If this distance becomes too great, signal repeaters or additional equipment may be necessary.

RRHs installed in outdoor environments must be designed to withstand various weather conditions, including extreme temperatures, rain, and humidity. This requires careful consideration of the equipment's durability and maintenance requirements.

As the network expands, more RRHs are added, leading to increased fiber requirements and potential capacity constraints in the fiber network. Careful scalability planning is necessary to avoid these issues.
