Understanding Emergency Position-Indicating Radiobeacons

An emergency position-indicating radiobeacon, or EPIRB, is a vital tool for anyone who ventures into remote or isolated areas. They're designed to send out a distress signal to emergency responders in the event of an emergency.

EPIRBs are typically used by sailors, pilots, and hikers who venture into areas with no cell phone reception. They're a crucial safety device that can save lives.

The International Maritime Organization (IMO) has established regulations for the use of EPIRBs in maritime environments. EPIRBs must be registered with the IMO to ensure that emergency responders can quickly locate the source of the distress signal.

In the event of an emergency, an EPIRB can send out a signal for up to 48 hours, providing emergency responders with valuable time to locate the source of the distress signal.

You might enjoy: International Distress Frequency

An EPIRB is a device used to alert search and rescue services in the event of an emergency. It does this by transmitting a coded message via the Cospas Sarsat network.

The Cospas Sarsat network is free to use and multinational, allowing EPIRBs to reach a wide range of rescue coordination centers. A 406 MHz distress frequency signal is sent via satellite and earth stations to the nearest rescue coordination center.

EPIRBs also transmit a homing signal via 121.5 MHz to help rescue services pinpoint the beacon's location. This signal can be received by vessels in the local area, triggering an 'Man overboard' alarm on their AIS screen.

EPIRBs can be set up to include built-in GNSS receivers, which enable rescue services to accurately locate your coordinates to within +/- 50 meters. These receivers can use multiple satellite systems, such as the US GPS or the EU's Galileo, for greater global coverage and faster detection.

EPIRBs are sometimes called GPIRBs if they include a built-in GNSS/GPS receiver for quicker location pinpointing.

For your interest: Location Awareness

Emergency position-indicating radiobeacons (EPIRBs) come in different types, each designed for specific environments.

There are Category I and Category II EPIRBs, which are 406/121.5 MHz devices, detectable by satellite anywhere in the world, and recognized by the Global Maritime Distress and Safety System (GMDSS).

Category I EPIRBs are float-free, automatically activated, and suitable for use on commercial offshore working vessels with passengers. Category II EPIRBs are similar, except they are manually activated, and some models are also water activated.

Here's a breakdown of the different types of EPIRBs:

EPIRBs are classified into different categories based on their features and functionality. Category I EPIRBs are float-free, automatically activated, and detectable by satellite anywhere in the world. They are recognized by the Global Maritime Distress and Safety System (GMDSS).

There are also Category II EPIRBs, which are similar to Category I but are manually activated. Some models are also water-activated. These devices are not as widely used as Category I EPIRBs.

Here's a breakdown of the main differences between Category I and Category II EPIRBs:

It's worth noting that Category I EPIRBs are the most recommended by the Coast Guard, as they provide the most accurate and reliable distress signal.

Cospas-Sarsat Compatible Frequencies are a crucial aspect of Emergency Position-Indicating Radio Beacons (EPIRBs). The 406 MHz frequency is internationally designated for use only for distress signals.

406 MHz EPIRBs use a signal frequency of 406.025-406.076 MHz ± 0.005 MHz. This frequency allows a satellite local user terminal to accurately locate the EPIRB and identify the vessel, anywhere in the world.

Cospas-Sarsat has defined standards for beacons, and the organization has established a system of channels for 406 MHz beacons. The channels are designated as follows:

Registration and regulations are crucial for the proper functioning of an Emergency Position-Indicating Radio Beacon (EPIRB). Registration of your EPIRB is mandated by Federal Communications Commission regulations and can save your life in case of an emergency.

The U.S. Coast Guard warns that a user's life may be saved as a result of registered emergency information, as it can respond more quickly to signals from registered beacons. Registration is free and can be done through the National Oceanic and Atmospheric Administration (NOAA) in the USA.

Registration regulations vary by country, but most require you to provide contact information and details about the vessel the EPIRB is to be used on. In the UK, registration is with the Maritime and Coastguard Agency, while in the USA it's through NOAA. It's essential to register your EPIRB as soon as you purchase it and to update your registration details if you change your phone number, address, or vessel.

Here are the agencies accepting 406 beacon registrations by country:

Registration is not only a requirement but also an essential step in ensuring a quick and effective response in case of an emergency.

Registration of EPIRBs is a critical step in ensuring your safety in emergency situations. It's mandated by Federal Communications Commission regulations and enforced by the Coast Guard.

Proper registration of your 406 MHz EPIRB can save your life by allowing the Coast Guard to respond more quickly to signals from registered beacons. This is because registered emergency information can be used to confirm a distress situation and arrange rescue efforts.

You must register your EPIRB with your local authority, such as the National Oceanic and Atmospheric Administration (NOAA) in the United States or the Maritime and Coastguard Agency (MCA) in the UK. Registration is free and provides essential details to rescue teams to expedite your rescue.

There is no charge to register 406 MHz beacons, and registration is mandatory for vessels and aircraft operating under International Convention for the Safety of Life at Sea (SOLAS) and International Civil Aviation Organization (ICAO) regulations. The following list shows the agencies accepting 406 beacon registrations by country:

You must re-register your EPIRB if you change your boat, address, or primary phone number, and you must inform the local government if you sell your EPIRB.

The FAA has been slow to transition to 406 MHz ELTs, despite a recommendation from the NTSB in 2000. The NTSB first recommended this change in 2000, but the FAA declined due to opposition from AOPA.

The U.S. National Transportation Safety Board has made this recommendation twice, with the most recent one in September 2007. The NTSB cited two recent accidents as evidence that switching to 406 MHz ELTs is necessary.

The NTSB's recommendation was based on the fact that 406 MHz ELTs are more effective than 121.5 MHz ELTs, as seen in one of the accidents they cited.

An EPIRB emits a digital 406 MHz distress signal, containing a unique 15-digit identifier, to the Cospas-Sarsat Satellite System. This signal is relayed to the nearest Rescue Coordination Center, initiating your rescue mission.

EPIRBs can be registered with a serial number or Maritime Mobile Service Identity (MMSI) number. For EPIRBs with a serial number, Search and Rescue forces retrieve your beacon registration, providing ownership details and additional emergency contacts. EPIRBs with an MMSI number require the EPIRB 15 Hex ID to be added to the relevant maritime database.

Expand your knowledge: List of Countries by Number of Internet Users

The Cospas-Sarsat system uses Doppler processing to determine the location of the beacon. Local-user terminals detecting nongeostationary satellites interpret the Doppler frequency shift as they pass over a beacon transmitting at a fixed frequency. The interpretation determines both bearing and range.

Here are the types of satellites in the Cospas-Sarsat network:

EPIRBs equipped with a GNSS/GPS receiver provide location accuracy typically within 100 meters.

EPIRBs emit a digital 406 MHz distress signal, containing a unique 15-digit identifier, to the Cospas-Sarsat Satellite System.

This signal is retrieved by Search and Rescue forces, who use it to determine your location and initiate a rescue mission. The signal is relayed to the nearest Rescue Coordination Center, which uses the EPIRB's 121.5 MHz homing signal, AIS location signal, and strobe lights to pinpoint your location for a safe return.

The satellites in the Cospas-Sarsat network are used to detect and locate EPIRBs, and there are three types of satellites in use: LEOSAR, MEOSAR, and GEOSAR.

For more insights, see: Advanced Mobile Location

Here's a breakdown of the detection and location process:

EPIRBs equipped with a GNSS/GPS receiver provide location accuracy typically within 100 meters, helping rescue coordination centers determine your position quickly and precisely.

EPIRBs equipped with a GNSS/GPS receiver provide location accuracy typically within 100 meters.

The 406 MHz EPIRB, for example, can be located with an accuracy of 2 to 5 km, which is much more accurate than devices operating on 121.5/243 MHz frequencies.

A 406 MHz EPIRB with an integral GPS navigation receiver can send accurate location as well as identification information to rescue authorities immediately upon activation.

In contrast, some older beacons can have a search area of up to 200 km, making it much harder for rescue teams to locate the source of the distress signal.

Modern 406-MHz beacons are accurate to 2 parts per billion, giving a search area of only 2 km.

Explore further: Radio Resource Location Services Protocol

Satellite Notification Devices, such as EPIRBs, are designed to send a distress signal to satellites in case of an emergency. They work by emitting a digital 406 MHz distress signal, containing a unique 15-digit identifier, to the Cospas-Sarsat Satellite System.

This signal is picked up by at least one satellite, which then transfers the signal to its ground control station. The ground station processes the signal and forwards the data, including approximate location, to a national authority. The national authority then forwards the data to a rescue authority, which uses its own receiving equipment to locate the beacon and commence rescue operations.

EPIRBs are registered to a vessel, whereas Satellite Emergency Notification Devices (SENDs) like SPOT and inReach are registered to a person. This means that if you switch to a new vessel, you'll need to re-register your EPIRB, but your SEND will still be correctly registered.

There are several types of satellites in the Cospas-Sarsat network, including LEOSAR, MEOSAR, and GEOSAR. These satellites work together to detect beacons and provide location information to rescue authorities.

Here are the different types of satellites in the Cospas-Sarsat network:

These satellites work together to provide global coverage and ensure that distress signals are received quickly and accurately.

EPIRBs can be deployed manually or automatically, depending on the bracket category and situation. In an automatic Float Free Category 1 bracket, the EPIRB releases when the Hydrostatic Release Unit (HRU) is submerged in water at a depth of 1.5 – 4 meters.

The release depth varies to accommodate different water temperatures, requiring HRU replacement every two years. This is crucial for ensuring the EPIRB's proper functioning.

EPIRBs in a Category 2 bracket require manual deployment and activation, which can be done above or below deck. Some users store their beacon in a Ditch bag, but caution is advised as EPIRBs activate upon water immersion, risking false alarms.

In Australia and New Zealand, “Class 3” EPIRBs lack water activation, requiring manual activation only, ensuring their performance isn’t affected by water exposure.

Automatic EPIRBs are water activated, and some EPIRBs also "deploy"; this means that they physically depart from their mounting bracket on the exterior of the vessel (usually by going into the water.)

For another approach, see: Radio-paging Code No. 1

For a marine EPIRB to begin transmitting a signal (or "activate") it first needs to come out of its bracket (or "deploy"). Deployment can happen either manually where someone must physically remove it from its bracket or automatically where water pressure will cause a hydrostatic release unit to separate the EPIRB from its bracket.

EPIRBs can be activated, depending on the circumstances, either manually (crewman flicks a switch) or automatically (when water contacts the unit's "sea-switch"). Activation should only be initiated in grave and imminent danger, where loss of life, limb, or valuable property is likely without emergency assistance.

Here's a brief summary of EPIRB bracket categories and their characteristics:

EPIRBs are designed to operate with satellites, transmitting a signal on the 406 MHz frequency that's internationally designated for distress only. This frequency allows for accurate location and identification of the vessel.

The 406 MHz EPIRB has a significant advantage over other devices, as it can be detected by both polar-orbiting COSPAS-SARSAT satellites and geostationary GOES weather satellites. This means it can send rescue authorities an instant alert, and even provide location information.

A new type of 406 MHz EPIRB, equipped with an integral GPS navigation receiver, became available in 1998. This device sends accurate location and identification information to rescue authorities immediately upon activation through both geostationary and polar-orbiting satellites.

EPIRBs are designed for vessels and activate automatically in the water, making them ideal for offshore or unattended situations.

However, this automatic activation feature is actually a limitation, as it can lead to accidental activation and increased costs for search and rescue services.

PLBs, on the other hand, are smaller, manually activated, and worn by crew – perfect for personal use. They don't have an automatic activation feature, which reduces the risk of accidental activation.

PLBs are also designed to be used anywhere in the world, on the sea and also on land, but they may not float and come with an additional flotation sleeve instead.

One key difference between EPIRBs and PLBs is their registration process – an EPIRB is registered to a vessel, while a PLB is registered to a person. This means if you switch to a new yacht, your PLB remains correctly registered.

PLBs have a three-stage activation process to prevent inadvertent activation, which is a safety feature that's not found in EPIRBs.

In terms of battery life, PLBs will transmit for a minimum of 24 hours and store for 6 years, while EPIRBs can transmit for at least 48 hours and have a battery life of up to 10 years.

There are alternative technologies to 406 MHz devices available in the marketplace. These devices don't meet the standard for 406 MHz devices.

Some of these alternative technologies don't have the same level of functionality as 406 MHz devices. They might not be as reliable or effective in emergency situations.

There are other personal devices available that don't meet the standard for 406 MHz devices.

AIS SART devices transmit AIS messages containing accurate GPS position information and include a GPS receiver and a transmitter on VHFAIS channels, so they show up on ship AIS receivers.

They are lightweight and can be used to equip inflatable liferafts. AIS-SART devices are allocated MMSI numbers in the range 970YYxxxx. They are distinct from traditional SAR radar transponders as they transmit AIS messages.

Check this out: Emergency Services Text Messages

The 406 MHz EPIRB was designed to operate with satellites, but there are some frequencies that are not supported by the Cospas-Sarsat system.

Marine VHF radio channels 15/16 are used only on the obsolete Class C EPIRBs.

The obsolete Inmarsat-E beacons transmitted to Inmarsat satellites on 1646 MHz UHF.

121.5 MHz VHF is still used for short-range location during a search and rescue operation, but satellite detection ceased on 1 February 2009.

243.0 MHz UHF was used prior to 1 February 2009, but is no longer compatible with the Cospas-Sarsat system.

Here are some frequencies that are no longer supported by Cospas-Sarsat:

The Emergency Position-Indicating Radiobeacon (EPIRB) has a fascinating history that dates back to the 1970s. The first EPIRBs were developed by the US Coast Guard and the US Navy to help locate people in distress at sea.

The first EPIRBs were relatively simple devices that used a radio transmitter to send out a signal to nearby aircraft and ships. These early devices were often battery-powered and had a limited range.

In the 1980s, the International Maritime Organization (IMO) began to standardize EPIRBs, requiring them to transmit on a specific frequency and meet certain performance standards. This led to the development of more reliable and efficient EPIRBs.

The IMO's standards for EPIRBs have been updated several times since the 1980s, with the most recent update occurring in 2013. This update included new requirements for EPIRBs to be capable of transmitting for at least 48 hours on a set of batteries.

Registration of your 406 MHz EPIRB is a crucial step in ensuring your safety in emergency situations. Proper registration can save your life by providing the Coast Guard with accurate information to respond quickly to distress signals.

The Coast Guard warns that unregistered EPIRBs can cause significant delays in rescue efforts, potentially costing lives. In fact, unregistered EPIRBs have been linked to several maritime fatalities since the satellite system became operational.

Registration is mandatory for all distress alerting beacons operating on 406 MHz, and it's free to register. The U.S. Coast Guard and other national authorities accept registrations, and you can check the list below for the agency accepting registrations in your country:

It's essential to register your EPIRB as soon as you purchase it, and to update your registration if you change your boat, address, or primary phone number.

As of 2019, the manufacture, importation, or sale of 121.5 MHz ELTs became prohibited in the United States per a Federal Communications Commission (FCC) final rule.

However, aircraft operators can still continue to use 121.5-MHz ELTs now installed in aircraft, and replacement parts are still available.

In fact, 121.5 MHz ELTs are still found on some private aircraft, which is perfectly legal.

But here's the catch: Cospas-Sarsat Satellites are not equipped to detect a 121.5 MHz ELT signal, so users must rely on an overflying aircraft that is within range of the crash site and listening to 121.5 MHz to receive the 121.5 signal.

In contrast, 406 MHz ELTs dramatically reduce the false alert impact on SAR resources, have a higher accident survivability success rate, and decrease the time to reach accident victims by an average of 6 hours.

The International Cospas-Sarsat Programme is a shining example of international cooperation, even during the Cold War era. It was formed in 1982 by a consortium of the USSR, the U.S., Canada, and France.

The programme's name, Cospas-Sarsat, is derived from the Russian words "COsmicheskayaSistema Poiska Avariynyh Sudov", which translates to "space system for the search of vessels in distress". This gives you an idea of the programme's focus on search and rescue operations.

The programme has grown to include 29 other countries, making it a truly international effort. The satellites used in the system include LEOSAR, GEOSAR, and MEOSAR.

These satellites communicate beacon data to ground stations, which then forward it to main control centers of each nation, allowing for a swift rescue effort. The programme defines standards for beacons, auxiliary equipment, ground stations, and communications methods.

Here's a breakdown of the Cospas-Sarsat Monitoring components:

The programme's standards are strictly regulated by international convention, ensuring that all 406 beacons meet certain criteria.

Testing 406 MHz EPIRBs can be done through its self-test function or by placing it in a container designed to prevent satellite reception.

It's essential to conduct a monthly self-test to verify your beacon's functionality. If the test is successful, your beacon is operational.

Testing a 406 MHz EPIRB by allowing it to radiate outside such a container is illegal.

The new EPIRB2 and EPIRB3 series offer NFC technology, enabling users to access EPIRB diagnostics via smartphones.

If the self-test fails, arrange for the beacon to be serviced to ensure it's working correctly.

The Ocean Signal Product App provides access to device data, including current battery life, self-test and GNSS test completion, activation duration, and detailed test results.

GNSS tests offer a map view pinpointing the test location, date and time, fix acquisition time, satellites used, and fix accuracy.

Readers also liked: Multi-Operator Radio Access Network

406 MHz beacons transmit for a quarter of a second immediately when turned on, and then transmit a digital burst once every 50 seconds thereafter.

The repetition period of these signals is designed to be randomized, so no two beacons will have all of their bursts coincident. This is achieved by randomizing the period around a mean value of 50 seconds, resulting in time intervals between transmission randomly distributed on the interval 47.5 to 52.5 seconds.

406 MHz beacons are compatible with the MEOSAR (DASS) system, making them the only beacons that will work with this system.

Here's a breakdown of the transmission schedule for 406 MHz beacons:

All 406 MHz beacons must be registered.
