Air-Ground Radiotelephone Service Guide

Author

Reads 6.2K

Snow-covered mountain with radio tower and evergreen trees under blue sky.
Credit: pexels.com, Snow-covered mountain with radio tower and evergreen trees under blue sky.

Air-ground radiotelephone service is a critical communication system for pilots and air traffic controllers. It allows for real-time voice communication between aircraft and ground stations.

The service operates on specific radio frequencies, typically between 118.0 and 135.975 MHz, to ensure clear communication.

Air-ground radiotelephone service is a must-have for safe and efficient flight operations.

History and Background

Air-ground radiotelephone service has a rich history that dates back to the 1920s. The first demonstration of air-to-ground radiotelephone technology occurred in 1923 at the Toulouse Air Show in France.

The first recorded air-to-ground radiotelephone service on a scheduled flight was in 1937 on the Chicago-Seattle route by Northwest Airlines. This marked the beginning of a new era in air travel communication.

In the early 1980s, AirFone started its service with experimental licenses, and the FCC formally allocated the spectrum in 1990. AirFone's service was initially limited to first-class passengers and was priced extremely high, which contributed to its decline in popularity.

AirFone's decline was further accelerated by the widespread availability of cellular telephones. By 2006, only two to three people per flight made a call using AirFone.

History

Dassault Falcon 7X Jet Plane of French Air Force Taking Off
Credit: pexels.com, Dassault Falcon 7X Jet Plane of French Air Force Taking Off

The history of in-flight communication is a fascinating story that spans nearly a century. It all began in 1923 with a demonstration of air-to-ground radiotelephone technology at the Toulouse Air Show in France.

The first recorded air-to-ground radiotelephone service on a scheduled flight was in 1937 on the Chicago-Seattle route by Northwest Airlines, marking a significant milestone in the development of in-flight communication.

AirFone, a service that allowed passengers to make phone calls from the air, was first introduced in the early 1980s under experimental licenses, with the FCC's formal allocation in 1990.

The service was initially only available to first-class passengers, but was later extended to economy class, with handsets installed in each row of seats. However, the service was always priced very high, at $3.99 per call and $4.99 per minute in 2006.

By 2005, Verizon AirFone's president was quoted as saying that only two to three people per flight made a call, highlighting the limited use of the service.

Here's an interesting read: Azure Communications Services

Background

Credit: youtube.com, How to do background research (History Research Process - Step 2)

In 1990, the Commission allocated four megahertz of spectrum for commercial Air-Ground Radiotelephone Service.

This spectrum was divided into ten paired channel blocks, which were allotted to specific geographic locations, essentially a national grid.

Each channel block contains 29 narrowband (6 kHz) communications channels and 6 very narrowband (3.2 kHz) control channels.

The Commission's rules required each licensee to have an exclusive control channel, share all the communication channels with other licensees in the band, and provide nationwide service.

Some ground station locations in North America and channel block assignments were predetermined consistent with bilateral agreements with Mexico and with Canada.

The number of communications channels limits the number of voice calls that can be simultaneously handled in a particular area.

The narrow bandwidth of these channels limits a service provider to voice and low-speed data services.

Only three of the six original licensees built systems and provided service, and two of those failed for business reasons.

Verizon Airfone remains the sole incumbent in the band, providing voice and low-speed data services.

If this caught your attention, see: China Communications Services

Title 47

Credit: youtube.com, Flight Service Stations MADE EASY (PPL Lesson 44)

Title 47 is a significant part of the air-ground radiotelephone service, and it's essential to understand its requirements. The FCC Form 601 applications for authorization to operate a general aviation air-ground station must contain administrative information, including the number of transmitter sites and the call sign of other facilities in the same area.

To operate a commercial aviation air-ground system, you'll need to meet the construction requirements, which include demonstrating substantial service within 5 years after grant of the authorization. This can be done by constructing and operating 20 ground stations, with at least one ground station in each of the 10 Federal Aviation Administration regions, or by providing service to the airspace of 25 of the 50 busiest airports.

The effective radiated power (ERP) of ground and airborne stations operating on the frequency ranges listed in § 22.857 must not exceed 500 Watts for ground station transmitters and 12 Watts for airborne mobile station transmitters. The ERP limits are in place to prevent interference with other services.

White and Red Air Plane in the Sky
Credit: pexels.com, White and Red Air Plane in the Sky

Commercial aviation air-ground system licensees may receive initial notification of interference from non-cellular part 90 licensees in the 800 MHz band. This notification is an important step in ensuring that the system operates without causing interference to other services.

The FCC has established two safe harbors for demonstrating substantial service: constructing and operating 20 ground stations, with at least one ground station in each of the 10 Federal Aviation Administration regions, or providing service to the airspace of 25 of the 50 busiest airports. These safe harbors provide a clear path for licensees to meet the substantial service requirement.

The 800 MHz air-ground radiotelephone service band plan and service rules have been reexamined by the Commission, and flexible rules have been adopted to enable interested parties to bid on licenses in three possible band configurations. Each configuration includes at least one spectrum block that will permit the provision of high-speed telecommunications services to the public onboard aircraft.

The technical channel pair assignment criteria established by the FCC provide substantial service volumes over areas with significant local and regional general aviation activity, while maintaining continuous nationwide in-route coverage. The criteria include distance separation for co-channel ground stations and dispersion requirements.

Technical Standards and Services

Credit: youtube.com, 90% of Private Pilot Air Traffic Control in One Flight | ATC Basics

The Federal Communications Commission reexamined the 800 MHz Air-Ground Radiotelephone Service band plan and service rules to promote the highest valued use of the spectrum for the provision of air-ground services that better meet the needs of the public.

To achieve this, the Commission adopted flexible rules that enable interested parties to bid on licenses in three possible band configurations. Each configuration includes at least one spectrum block that will permit the provision of high-speed telecommunications services to the public onboard aircraft.

Flexible technical and operational rules will be used to determine the best technological configuration of the band and the number of competitors for air-ground communications over multiple platforms.

Technical Standards

The Federal Communications Commission (FCC) sets strict technical standards for air-ground telecommunications services to ensure safe and reliable communication.

Frequency stability is crucial to prevent interference, and equipment used in these services must be able to maintain a stable frequency within the authorized bands of operation, accounting for Doppler frequency shifts.

Credit: youtube.com, Get to Know About Technical Standards | International Standards | Role of Technical Standards

The FCC has designated specific frequency bands for commercial aviation air-ground systems, including the 849-851 MHz and 894-896 MHz bands, which are available for paired nationwide exclusive assignment to licensees.

The peak effective radiated power (ERP) of airborne mobile station transmitters must not exceed 12 Watts, while ground station transmitters must not exceed 500 Watts.

Transmitting power limits vary between ground and airborne mobile transmitters, with ground stations limited to 100 Watts and airborne mobile transmitters limited to 25 Watts.

Here's a summary of the transmitting power limits for ground and airborne mobile transmitters:

The FCC has also established rules for standby facilities, eliminating the need for separate authorization to install standby transmitters in case of transmitter failure or maintenance.

No individual or entity may hold a controlling interest in licenses authorizing the use of more than three megahertz of spectrum in the 800 MHz commercial aviation Air-Ground Radiotelephone Service frequency bands.

The FCC has revised and eliminated certain rules governing the 400 MHz Air-Ground Radiotelephone Service, redesignating current sections and deleting superfluous language.

Intriguing read: Ground Station

Information Exchange

Credit: youtube.com, Overview of Standards

Public safety and commercial aviation air-ground system licensees need to exchange information to avoid interference. Prior notification is a key aspect of this process.

Commercial aviation air-ground system licensees must provide public safety/CII licensees with specific information at least 10 business days before activating a new ground station or modifying an existing one. This information includes the location, antenna manufacturer, model number, height above ground level, and up tilt angle.

The purpose of prior notification is informational only, and public safety/CII licensees do not have the right to accept or reject the activation of a proposed ground station. They can, however, advise commercial aviation air-ground system licensees if they believe a proposed ground station will generate unacceptable interference.

Public safety/CII licensees can also alert commercial aviation air-ground system licensees to possible interference, allowing them to make voluntary changes in ground station parameters. This can help prevent interference issues from arising in the first place.

Frequency and Channel Management

Credit: youtube.com, What Radio Frequencies Are Used In Air-Ground Communication? - Air Traffic Insider

Frequency and channel management play a crucial role in air-ground radiotelephone service. The FCC has allocated two separate frequency bands for this purpose: one at 454/459 MHz and the 800 MHz range.

The 450 MHz General Aviation network, administered by Mid-America Computer Corporation, requires the use of instruments manufactured by Terra and Chelton Aviation/Wulfsberg Electronics, and marketed as the Flitephone VI Series.

The 800 MHz band is divided into 10 blocks of paired uplink/downlink narrowband ranges (6 kHz) and six control ranges (3.2 kHz). Here's a list of the communication channel pairs allocated for general aviation air-ground service:

Channel Pair Assignment Criteria

To ensure a smooth and efficient channel pair assignment, the FCC has established some key criteria. The rules in this section are intended to provide substantial service volumes over areas with significant local and regional general aviation activity.

The FCC requires a proposed ground transmitter to be at least 800 kilometers from the nearest co-channel ground transmitter in the United States, its territories and possessions. This is to prevent interference and ensure reliable communication.

Male construction worker using radio on a building site, wearing a safety helmet, communicating effectively.
Credit: pexels.com, Male construction worker using radio on a building site, wearing a safety helmet, communicating effectively.

Dispersion is also a critical factor in channel pair assignment. The FCC will only grant an application if there are no more than five different communication channel pairs already assigned to ground transmitters within a 320 kilometer radius of the proposed antenna location.

The FCC has specific requirements for distance separation, including a minimum of 1000 kilometers from the nearest co-channel ground transmitter in Canada. This is to ensure that the proposed channel pair does not interfere with existing systems.

In the case of commercial aviation air-ground systems, the 849-851 MHz and 894-896 MHz frequency bands are designated for paired nationwide exclusive assignment.

Frequencies

Frequencies play a crucial role in air-ground communication. The FCC has allocated two separate frequency bands for this purpose: 454/459 MHz and 800 MHz.

The 454/459 MHz band is primarily used for general aviation air-ground service, with frequencies allocated for signaling and communication channels. For example, the signaling channel pair is 454.675 MHz for ground stations and 459.675 MHz for airborne mobile subscribers.

Take a look at this: Air Band Frequencies

Credit: youtube.com, Understanding the Radio Frequency Spectrum (#715)

The 800 MHz band, on the other hand, is used for commercial aviation air-ground systems, with frequencies allocated in the 849-851 MHz and 894-896 MHz bands.

Here's a breakdown of the signaling and communication channel pairs for the 454/459 MHz band:

Note that channel 454.675 MHz is assigned to each ground station for automatically alerting airborne mobile stations of incoming calls.

Pilots and Air Traffic Control

Pilots rely on constant communication with air traffic controllers to navigate safely through the sky.

Pilots get instructions on their flight path and altitude, which helps them stay on course.

They report their position and any unusual events to air traffic controllers, keeping them informed about the flight's progress.

Air traffic controllers can warn pilots about bad weather or other planes nearby, preventing potential hazards.

This communication is crucial for preventing accidents and ensuring flights run smoothly.

Expand your knowledge: Air Traffic Website

Licenses and Applications

To operate a general aviation air-ground station, you'll need to file an FCC Form 601 application, which must include administrative information, location description, and technical details about your transmitter site.

Credit: youtube.com, How do I get my FCC Restricted Radiotelephone RR Operator Permit? Airline Pilot Job Prep #aviation

The application must specify the number of transmitter sites for which authorization is requested, as well as the call sign(s) of other facilities in the same area that are ultimately controlled by the real party in interest.

Individuals applying to operate a general aviation airborne mobile station must file FCC Form 409 (Airborne Mobile Radio Telephone License Application), which is a requirement that's unique to the Air-Ground Radiotelephone Service.

However, the FCC has eliminated the requirement for authorization to operate general aviation airborne mobile stations in the Air-Ground Radiotelephone Service, and has also eliminated FCC Form 409.

General Application Requirements

To get a general aviation air-ground application approved, you'll need to provide some specific information. The FCC Form 601 application must contain the applicable supplementary information described in the general aviation air-ground application requirements.

The number of transmitter sites for which authorization is requested is a crucial piece of information. You'll also need to provide the call sign(s) of other facilities in the same area that are ultimately controlled by the real party in interest to the application.

Lion Air Boeing 737 aircraft captured mid-air during flight in Banten, Indonesia.
Credit: pexels.com, Lion Air Boeing 737 aircraft captured mid-air during flight in Banten, Indonesia.

You'll need to provide a detailed location description, including city, county, state, geographic coordinates (NAD83) correct to ±1 second, site elevation above mean sea level, proximity to adjacent market boundaries and international borders. The antenna height to tip above ground level, antenna gain in the maximum lobe, and the electric field polarization of the wave emitted by the antenna when installed as proposed are also required.

The center frequency of each channel requested, the maximum effective radiated power, any non-standard emission types to be used, including bandwidth and modulation type, and the transmitter classification (e.g. ground or signaling) must also be included.

Renewal of Call Sign Knkg804

Renewal of Call Sign KNKG804 is a significant development in the world of licenses and applications. Verizon Airfone Inc. was granted a non-renewable license for a five-year term, commencing on the effective date of this Report and Order. This license is subject to certain conditions.

Credit: youtube.com, How to RENEW your FCC Amateur Radio License

The company must cease its existing narrowband operations in the lower 1.5 MHz portion of each 2 MHz air-ground band within 24 months of the initial date of grant of a new spectrum license. This is a crucial step towards implementing band plans 1 or 2.

If band plan 1 or 2 is implemented, Verizon Airfone may relocate its incumbent operations to the upper 0.5 MHz portion of each 2 MHz band. This relocation is subject to specific frequency allocations.

The existing power limits for ground stations (100 Watts ERP) and airborne mobile stations (30 Watts ERP) will become license terms. This is a significant change for Verizon Airfone.

The company must also coordinate any technical changes within 885 kilometers (550 miles) of the U.S.-Canadian or U.S.-Mexican borders with the appropriate air-ground licensees in those countries. This is a critical step in ensuring international coordination.

Here are the specific conditions of the license:

  • If band plan 1 or 2 is implemented, Verizon Airfone must cease its existing narrowband operations in the lower 1.5 MHz portion of each 2 MHz air-ground band within 24 months.
  • If band plan 1 or 2 is implemented, Verizon Airfone may relocate its incumbent operations to the upper 0.5 MHz portion of each 2 MHz band.
  • If band plan 3 is implemented, Verizon Airfone must cease its existing narrowband operations in the upper 1.5 MHz portion of each 2 MHz air-ground band within 24 months.
  • If band plan 3 is implemented, Verizon Airfone may relocate its incumbent operations to the lower 0.5 MHz portion of each 2 MHz band.
  • The existing § 22.867 power limits for ground stations (100 Watts ERP) and airborne mobile stations (30 Watts ERP) will become license terms.
  • The existing § 22.861 out-of-band and spurious emission limits will become license terms.
  • The authorized emission bandwidth of any transmission from the existing system may not exceed 6 kHz.

Verizon Airfone must also maintain and provide to the FCC and the new 800 MHz air-ground licensee(s) a current list of the locations and channels used at all ground stations. This is essential for providing interference protection to the existing system's operations.

Target Audience

View of air traffic control towers at Amsterdam Schiphol Airport under clear blue sky.
Credit: pexels.com, View of air traffic control towers at Amsterdam Schiphol Airport under clear blue sky.

The target audience for licenses and applications is quite specific. Pilots are the primary users of air-ground radiotelephone service.

They use it for important safety and operational messages with air traffic control. Passengers might also use it, but this has changed over time.

Competitive Considerations

The Federal Communications Commission (FCC) regulates the air-ground radiotelephone service to ensure fair competition among providers.

Air-ground radiotelephone service providers must meet the same technical standards to ensure seamless communication between aircraft and ground stations.

The FCC requires providers to use standardized frequencies to avoid interference and ensure reliable communication.

The Commission also sets rules for the allocation of frequencies to prevent overcrowding and promote efficient use of the spectrum.

To ensure fair competition, the FCC prohibits providers from engaging in anti-competitive practices, such as predatory pricing or exclusive agreements.

The Commission monitors the market to prevent any single provider from dominating the air-ground radiotelephone service industry.

The FCC's regulations aim to strike a balance between promoting competition and ensuring the safety of air traffic.

Safety and Emergency Procedures

Credit: youtube.com, AVENIRMicro Air-To-Ground Communication for Public Safety

Air-ground radiotelephone service is a vital tool in ensuring flight safety. It allows for quick communication during emergencies, which can be a matter of life and death.

Pilots can get immediate updates on weather changes, helping them make informed decisions about flight routes and altitudes. This can save lives and prevent accidents.

Air traffic controllers can guide planes away from danger, using this service to coordinate with pilots and other air traffic controllers. This helps prevent collisions and ensures a smooth flow of air traffic.

  • Quick communication during emergencies.
  • Immediate updates on weather changes.
  • Guidance from air traffic controllers to avoid danger.

Interference Resolution Procedures

If you're dealing with interference, it's essential to follow the proper procedures to minimize its impact.

First, identify the source of the interference and assess its severity. This can be done by following the steps outlined in the "Identifying Interference" section.

In the event of electrical interference, switch off the affected equipment and unplug it from the power source. This is crucial to prevent further damage or electrical shock.

Low-Angle Photo of N Seoul Tower
Credit: pexels.com, Low-Angle Photo of N Seoul Tower

To resolve communication interference, try changing the frequency or channel used by the affected device. This can be done by consulting the device's user manual or contacting the manufacturer for assistance.

In some cases, interference can be resolved by simply relocating the affected device to a different area. For example, moving a radio away from a source of electrical interference can improve its reception.

Here's an interesting read: Medical Device Radiocommunications Service

Ensuring Flight Safety

Ensuring Flight Safety is crucial, and it's great to know that air-ground radiotelephone service plays a big role in this. It allows quick communication during emergencies.

Pilots can get immediate updates on weather changes, which is a lifesaver during turbulent weather. This helps them make informed decisions to keep everyone on board safe.

Air traffic controllers can guide planes away from danger, which is a huge relief for pilots and passengers alike. They can spot potential hazards and steer planes to safety.

Here's a quick rundown of the benefits of air-ground radiotelephone service:

  • Quick communication during emergencies
  • Immediate updates on weather changes
  • Air traffic controllers can guide planes away from danger

This constant link helps keep everyone on board safe, and that's what matters most.

Technical Details

Credit: youtube.com, How Does Air-Ground Communication Work? - Air Traffic Insider

Air-ground radiotelephone service relies on a simple yet effective technology. The process starts with someone on the plane speaking, which turns their voice into radio signals.

These radio signals travel through the air to a ground station. From there, the call is connected to the regular phone network.

In reverse, calls coming to the plane work the same way, with radio signals traveling from the ground station to the plane.

How It Works

The technology behind in-flight phone calls is quite fascinating. Radio signals are used to transmit voice conversations between the plane and the ground station.

These radio signals travel through the air to a ground station, where the call is connected to the regular phone network. This is the same process used for calls coming to the plane, allowing people on board to make and receive calls.

Here's a step-by-step breakdown of how it works:

  • Someone on the plane speaks, and their voice is turned into radio signals.
  • These signals travel through the air to a ground station.
  • The ground station then connects the call to the regular phone network.
  • It works the same way in reverse for calls coming to the plane.

It's worth noting that ground stations are required to continuously transmit a modulated signal on a channel with a power between 10 and 20 dB lower than the normal transmitting power when available but idle.

In-Flight Communication Alternatives

Credit: youtube.com, GRCon22 (Lightning Talk) Analysis of Alternatives for In Flight Connectivity by Pete

In-flight communication has come a long way, and it's no longer limited to air-ground radiotelephone service. This technology is still used by pilots, but it's not the only option available to passengers.

Modern alternatives for in-flight communication include new technologies that offer more convenient and efficient ways to stay connected during flights. Air-ground radiotelephone service is still used by pilots, especially for official communication.

Wi-Fi connectivity is one of the most popular alternatives, allowing passengers to stay connected with family and friends, check emails, and browse the internet.

Curious to learn more? Check out: Alternatives to Cox Cable

Frequently Asked Questions

What is the purpose of radiotelephony?

Radiotelephony is used to clarify, simplify, and standardize spoken communications over two-way radios in various settings. Its purpose is to ensure clear and effective communication in critical situations.

Lee Mohr

Writer

Lee Mohr is a skilled writer with a passion for technology and innovation. With a keen eye for detail and a knack for explaining complex concepts, Lee has established himself as a trusted voice in the industry. Their writing often focuses on Azure Virtual Machine Management, helping readers navigate the intricacies of cloud computing and virtualization.

Love What You Read? Stay Updated!

Join our community for insights, tips, and more.
