Weightless wireless communications is a new generation of wireless technology that's designed to be low power, low cost, and highly efficient. It's ideal for machine-to-machine (M2M) and Internet of Things (IoT) applications.

Weightless technology uses a unique approach to wireless communication, where devices only transmit data when they need to, reducing power consumption and increasing battery life. This approach is known as "listen before talk" or LBT.

Weightless wireless communications operates on a variety of frequencies, including the 800 MHz and 2.4 GHz bands. It's also designed to be highly scalable, making it suitable for a wide range of applications, from smart energy meters to industrial automation.

What is Weightless?

Weightless is a wireless connectivity technology designed for the Internet of Things (IoT). It delivers wireless connectivity for low power, wide area networks (LPWAN) specifically designed for IoT.

Weightless technology is simply better, offering fully acknowledged 2-way communication with the best in class quality of service. It supports data rates ranging from 200bps to 100kbps.

Credit: youtube.com, Low Power Wide Area Networking for IoT - Weightless Technology

One of the key features of Weightless is its ability to enable higher capacity than existing LPWAN and cellular technologies for uplink-dominated traffic with short-to-medium payload sizes. This is achieved through the use of common commercially-available chipsets that support both stationary and mobile end devices.

Weightless also utilizes low-power, innovative handover, cell re-selection and roaming methods, as well as advanced reliability features like fast network acquisition, paging, FEC, ARQ, power control and adaptive channel coding.

Here are some of the key characteristics of Weightless:

  • Low power consumption
  • Long range (up to 10Km)
  • High capacity
  • Low cost ($2 vs $3000)

Weightless is an open standard, which means it's free for anyone to use and implement. Its low cost, low power consumption, long range, and high capacity make it an ideal solution for IoT applications.

Take a look at this: Bluetooth Low Energy Audio

Additional reading: WirelessHD

Key Features and Specifications

The Weightless technology is designed for low-cost, low-power communication systems. It operates in the white space between TV channels.

Weightless-W uses time-division duplex technology with spread spectrum frequency hopping to minimize interference, and variable spreading factors to increase range and accommodate low-power devices. This technology is based on the original Weightless specification developed in 2011 by engineers at Neul in Cambridge, UK.

Credit: youtube.com, Fundamentals of RF and Wireless Communications

Key Features of Weightless:

  • Reliable bidirectional communication
  • Supports both network-originated and device-originated traffic
  • Operates over the whole range of license-exempt sub-GHz ISM/SRD bands for global deployment
  • Adaptive data rate and Forward Error Correction from 625 bps to 100 kbps
  • Transmit power control for both downlink and uplink
  • Acknowledgment and retransmission
  • Flexible channel assignment for frequency re-use
  • Time-synchronized base stations for efficient radio resource scheduling
  • Fully acknowledged communications
  • Auto-retransmission upon failure
  • Supports narrowband channels (12.5 kHz), licensed spectrum operation and frequency hopping
  • Radio resource management and scheduling across the overall network
  • NIST-compliant authentication to the network
  • AES-128 encryption as baseline, extensible cipher suites for future-proofing
  • Radio resource management and scheduling across the overall network
  • Fast network acquisition and frequency/time synchronization
  • Ultra-low power
  • PSK/GMSK modulation for optimal power amplifier efficiency
  • Interference-immune offset-QPSK modulation using spread spectrum
  • Adaptive transmit power and data rate to maximize battery life
  • 4µA sleep mode

Weightless-P, the latest Weightless technology, offers two-way features and quality of service tiers, and operates with a 12.5 kHz narrowband channel.

Specifications and Features

The Weightless technology offers a range of specifications and features that make it an attractive option for IoT applications.

The Weightless-W specification is based on time-division duplex technology with spread spectrum frequency hopping, which minimizes the impact of interference.

This technology allows for variable spreading factors, increasing the range at the expense of lower data rates, and accommodating low-power devices with low data rates.

Weightless-W operates over the whole range of license-exempt sub-GHz ISM/SRD bands for global deployment, including 433/450/470/868/915/923 MHz.

It supports both network-originated and device-originated traffic, with FDMA+TDMA in 12.5 kHz narrowband channels offering optimal capacity for uplink-dominated traffic from a very large number of devices with moderate payload sizes.

The technology also features adaptive data rate and Forward Error Correction from 625 bps to 100 kbps to optimize radio resource usage depending on device link quality.

A close-up view of hands interacting with a smartphone in a dim indoor setting, highlighting technology use.
Credit: pexels.com, A close-up view of hands interacting with a smartphone in a dim indoor setting, highlighting technology use.

Weightless-P offers two-way features and quality of service tiers, with a 12.5 kHz channel relatively narrowband.

It uses Gaussian minimum shift keying (GMSK), which is a more standard modulation, and quadrature phase shift keying (QPSK), which is much more advanced.

Weightless-P doesn’t require a TCXO because of the wider-band MSK, and its range is currently quoted at roughly two kilometers.

Weightless-N is an ultra-narrowband system, similar to SigFox, using differential BPSK in narrow frequency channels, intended for uplink sensor data.

It requires a temperature compensated crystal oscillator (TCXO) and has a relatively unbalanced link budget, which can be problematic.

Weightless-N is ideal for sensor-based networks, temperature readings, tank level monitoring, metering, and more.

If this caught your attention, see: Monitor Temperature Remotely

Cost, Capacity, Oscillation

The cost of implementing a Weightless-N network can be higher due to the use of software defined radio (SDR) hardware, which creates hundreds to thousands of small binary phase-shift keying (BPSK) channels.

This architecture allows for a lot of capacity, but it's also more expensive to set up. In contrast, LoRa is more forgiving when it comes to oscillator quality.

Weightless-N end nodes can also be more expensive, as they often require a temperature compensated crystal oscillator (TCXO) to maintain stable frequency despite temperature variations.

Comparison and Analysis

Credit: youtube.com, Two-Way Radio Communications vs Cellular/Smartphone | Wireless Communications Explained Podcast

Weightless is a viable alternative to LoRa for IoT systems, especially if you're looking to avoid proprietary radio silicon from Semtech.

Functionally, Weightless-N is similar to LoRaWAN, both being uplink-focused data systems.

Weightless offers a choice for building an IoT system based on an available standard, which can be a challenge for engineers or firms to navigate.

Curious to learn more? Check out: Security System Wireless Cameras

N vs Sigfox

Weightless-N and SigFox are similar from a technology perspective, but they differ in their approach to the market.

Weightless-N is a standard, which means another company must create an IoT solution around it. N-Wave is the leader in this space and sells a lot of hardware for Weightless-N to companies trying to create a Weightless network.

SigFox, on the other hand, offers a complete out-of-the-box solution. This makes it a more straightforward choice for users looking for a turn-key IoT solution.

Weightless-N is ideal for sensor-based networks, temperature readings, and other applications that require uplink sensor data.

Woman's hands typing on a wireless laptop at a modern office desk, highlighting technology in business.
Credit: pexels.com, Woman's hands typing on a wireless laptop at a modern office desk, highlighting technology in business.

Weightless-P vs Link: What's the difference?

Weightless-P and Symphony Link are both designed for private networks, but Symphony Link's range performance is arguably better due to its use of LoRa instead of MSK.

Symphony Link's LoRa technology gives it a range advantage over Weightless-P.

Weightless-P, on the other hand, uses Gaussian minimum shift keying (GMSK) and quadrature phase shift keying (QPSK), which are more standard and advanced modulation techniques, respectively.

Weightless-P doesn't require a TCXO, unlike some other Weightless technologies.

Weightless-P is ideal for private networks and more sophisticated use cases where both uplink data and downlink control are important.

Here's a comparison of Weightless-P and Symphony Link:

Weightless-P offers two-way features and quality of service tiers, which are important for more complex use cases.

Weightless-P is the latest Weightless technology, expected to launch in early 2016.

Implementation and Architecture

Weightless-N uses a differential binary phase shift keying (DBPSK) digital modulation scheme to transmit within narrow frequency bands using a frequency hopping algorithm for interference mitigation and enhanced security.

Credit: youtube.com, A Primer On Digital & Wireless Communication: Intuitive and Hands-on MATLAB Project

This approach provides encryption and implicit authentication using a shared secret key regime to encode transmitted information via a 128-bit AES algorithm. The technology supports mobility with the network automatically routing terminal messages to the correct destination.

Weightless-W, on the other hand, uses time-division duplex operation with frequency hopping and variable spreading factors to increase range and accommodate low-power devices in frequency bands, or channels, within the terrestrial television broadcast band.

It's worth noting that the system architecture of Weightless is based on a star topology, composed of end-device communication modules and base stations. Each base station connects to the backend system through Ethernet or 4G backhaul for data processing and applications.

A fresh viewpoint: World Wireless System

Implementation

Weightless-N uses a differential binary phase shift keying (DBPSK) digital modulation scheme to transmit within narrow frequency bands using a frequency hopping algorithm for interference mitigation and enhanced security.

This technology provides encryption and implicit authentication using a shared secret key regime to encode transmitted information via a 128-bit AES algorithm.

Credit: youtube.com, Implementation architecture introduction

Weightless-W, on the other hand, employs time-division duplex operation with frequency hopping and variable spreading factors to increase range and accommodate low-power devices in frequency bands.

Each base station queries a central database to determine which network the terminal is registered to decode and route data accordingly.

A network of base stations communicates with the Internet, or a private network, to pass information from devices to a computer system; and data back to the devices.

The downlink to devices uses time slots (TDMA), and the uplink to the base station is divided into sub-channels so that several devices can communicate with the base station.

Weightless-W channels used by a nearby television transmitter are identified and left unaffected, while channels not being used for broadcasting television can be allocated for use by Weightless devices.

For another approach, see: Aerial Base Station

System Architecture

The system architecture of Weightless network is built on a star topology, which allows for efficient communication between devices and the base station.

Telecommunication tower under cloudy and blue sky. Wireless communication and information technology concept
Credit: pexels.com, Telecommunication tower under cloudy and blue sky. Wireless communication and information technology concept

This topology is composed of end-device communication modules and base stations, which work together to enable full bidirectional communication through the Weightless protocol.

The Weightless protocol also manages device authorization and radio resource allocation, ensuring that data is transmitted securely and efficiently.

Each base station can connect to multiple end-device communication modules, forming a crew that can communicate with the base station.

Ubiik offers base stations for both indoor and outdoor environments, making it easy to meet customer needs.

Base stations connect to the backend system through Ethernet or 4G backhaul for data processing and applications.

The network uses a narrowband 100 kHz frequency, which is divided into 8 sub-channels of 12.5 kHz each.

This narrowband approach allows for high-reliability in large-scale networks, even with frequent uplink transmissions.

Starter Kit

To get started with implementing and architecting a solution, you'll want to begin with a solid foundation. This is where the Starter Kit comes in, providing a comprehensive package to help you hit the ground running.

Sleek white wireless router with four antennas emitting soft blue and pink light.
Credit: pexels.com, Sleek white wireless router with four antennas emitting soft blue and pink light.

The Weightless Starter Kit includes an Indoor Base Station with an antenna, and two Evaluation boards with antennas. This setup allows you to test and evaluate the system in a controlled environment.

One of the key benefits of the Starter Kit is the 60-day free access to Ubiik Cloud, giving you ample time to explore the features and capabilities of the system.

Benefits and Advantages

Weightless offers the promised performance, network reliability and security characteristics of carrier-grade solutions.

One of the key benefits of Weightless is its low cost, with terminal costs as low as $2 compared to $3000 for other solutions. This makes it an attractive option for IoT applications.

Weightless technology delivers wireless connectivity for low power, wide area networks (LPWAN) specifically designed for the Internet of Things. StandardTerminal CostNetwork CostWeightless-NVery LowVery LowWeightless-PLow-MediumMediumWeightless-WLowMedium

Why Choose?

Choosing the right solution can be overwhelming, but let's break it down. Weightless offers the promised performance of carrier-grade solutions.

Bold white letters spelling WHY on a pink textured background for conceptual design.
Credit: pexels.com, Bold white letters spelling WHY on a pink textured background for conceptual design.

This means you can expect reliable and efficient results. I've seen firsthand how important it is to have a solution that delivers on its promises.

Weightless also provides network reliability, which is crucial for any operation. You can count on it to get the job done.

Security is another key aspect of Weightless, offering the security characteristics of carrier-grade solutions. This gives you peace of mind knowing your data is protected.

Need for Technology Like

The argument for a need for technology like Weightless is solid. WiFi is already everywhere, and it's cheap and readily available. But, as we'll see, Weightless has some unique advantages that make it a compelling choice for certain applications.

Weightless technology delivers wireless connectivity for low power, wide area networks (LPWAN) specifically designed for the Internet of Things. This is a key benefit, as it allows for long-range communication with low power consumption.

One of the main advantages of Weightless is its low cost. According to the article, the cost of Weightless is around $2, compared to $3000 for other technologies. This makes it an attractive option for IoT projects.

Smart home wireless network router device
Credit: pexels.com, Smart home wireless network router device

Here are some of the key features of Weightless:

In fact, Weightless-P is an ultra-high performance LPWAN connectivity technology that is specifically designed for the IoT. It offers excellent capacity and scalability, making it an ideal choice for private networks.

So, while WiFi is certainly a popular choice for IoT projects, Weightless has some unique advantages that make it a compelling choice for certain applications. Its low cost, long range, and high capacity make it an attractive option for IoT projects that require a lot of data transmission.

Market and Industry

The weightless wireless communications market is growing rapidly, with a projected value of $1.3 billion by 2025. This growth is driven by the increasing demand for wireless connectivity in various industries.

Weightless technology is being adopted by various sectors, including smart cities, industrial automation, and transportation systems. The technology's ability to provide low-power, low-latency connectivity is making it an attractive solution for these applications.

The weightless market is expected to be dominated by industrial automation, which will account for 40% of the market share by 2025.

Identifies Market Gap

Credit: youtube.com, Identifying Market Gaps and Opportunities

Weightless has identified a gap in the market with its innovative technology, particularly in the areas of range and battery life, where it has unmatched advantages.

The chart from nwave, a company using the Weightless-N technology, clearly shows these advantages.

Weightless has adopted an open standard, which could be a major game-changer if enough of the market adopts it.

The headlining feature of the Weightless technology is its use of the UHF band, previously occupied by television transmission.

Smart City Networks

Smart City Networks are being implemented in various parts of the world. One such example is the Weightless-N Smart City networks in Denmark and the UK.

Weightless-N technology uses the unlicensed sub-GHz ISM band. This is an open standard, and the SDK is available royalty-free.

The Weightless-N technology has been deployed in Copenhagen, Esbjerg, London, and Cambridge.

IoT Hardware Hard to Find

The shortage of IoT hardware is a pressing issue, with 70% of IoT projects facing delays due to component availability.

A unique Thai tower facade features modern antennas under a clear blue sky.
Credit: pexels.com, A unique Thai tower facade features modern antennas under a clear blue sky.

Many companies are struggling to find the right components, with 60% of them experiencing difficulties in sourcing the necessary parts.

This shortage is caused by an over-reliance on a few large suppliers, which has left the market vulnerable to disruptions.

As a result, companies are having to get creative with their designs, using alternative components or even re-designing their products to work with what's available.

The shortage of IoT hardware is not just a temporary issue, but a long-term problem that will require a fundamental shift in the way we approach component sourcing.
