Videotelephone History and Modern Applications

The videotelephone has a rich history that spans over a century. The first videotelephone was invented in 1927 by AT&T's Bell Labs, which allowed for real-time video transmission over phone lines.

The first commercial videotelephone service was launched in 1964 by AT&T, but it was expensive and not widely adopted. It wasn't until the 1970s that videotelephones became more mainstream, with the introduction of satellite-based systems.

The modern videotelephone has come a long way since its inception. With the advent of the internet and mobile devices, videotelephones have become ubiquitous and affordable, with services like Skype and Zoom allowing for free or low-cost video calls.

Today, videotelephones are used for both personal and professional purposes, from staying in touch with loved ones to conducting business meetings remotely.

Intriguing read: First Net Phone Service

The idea of a videophone was first promoted at the 1939 New York World's Fair by AT&T, with a display of experimental video for telephone service.

AT&T continued to develop and promote the concept, with the Picturephone Mod I being unveiled at the 1964 World's Fair in Queens, where people lined up to make calls to a corresponding exhibit at Disneyland.

The first transcontinental videocall was made on April 20, 1964, between the World's Fair and Disneyland, marking a significant milestone in the development of videotelephone technology.

The Picturephone Mod I was a technological tour de force, featuring a silicon photodiode array camera, a zoom lens, and some graphics capability, with a 5.25 x 5 inch screen showing a single person, a full-motion black and white picture at 250 lines resolution.

AT&T's Picturephone units were also featured at the Telephone Pavilion at Expo 67 in Montreal, Canada, where demonstration units were available for the public to test.

The first public videophone booths were installed in the lobbies of New York's Grand Central Terminal, the National Geographic Society Headquarters in Washington D.C., and Chicago's Prudential Building in 1964, but they were limited by their high cost and were eventually closed by 1968.

Despite its high price tag, the idea of a picturephone captured the public's imagination, with appearances in popular culture, including a scene in Stanley Kubrick's 2001: A Space Odyssey, and regular mentions in magazines like Popular Science.

AT&T continued to develop and promote the Picturephone, releasing its internal publication, Record magazine, in June 1969, which detailed the massive effort and investment the company had made in the technology and its high hopes for its future.

The Picturephone Meeting Service was released in 1982, but it was still overly expensive, even for large companies, and was eventually discontinued.

The VideoPhone 2500 was released in 1992, but it was also met with poor sales and was eventually discontinued, marking the end of AT&T's efforts to develop a commercial videophone product.

Video compression is a crucial step in transmitting high-quality video over the internet. It reduces the size of the video file, making it easier to stream and download.

The first video telephones used analog compression, which was limited in its ability to transmit clear images. This led to pixelated and distorted video.

The development of digital compression in the 1970s and 1980s greatly improved video quality. Digital compression uses algorithms to compress the video file, reducing its size while preserving quality.

The H.261 standard, introduced in 1988, was the first widely adopted digital compression standard. It allowed for a 30:1 compression ratio, making it possible to transmit video over the internet.

The H.261 standard was later improved upon by the H.263 standard, which offered even greater compression ratios. This allowed for even higher quality video to be transmitted over the internet.

Mitsubishi marketed its VisiTel LU-500 image phone in 1988, costing about US$400 and aimed at the consumer market. It had a larger black and white display, but reduced capabilities compared to other image phones.

The VisiTel LU-500 was one of several image transfer phones marketed by Japanese electronic manufacturers in the late 1980s. Sony's PCT-15 and Panasonic's WG-R2 and KX-TV10 were also popular options.

These early Japanese videophones were quite pricey, with the Sony PCT-15 costing US$500 and the Panasonic KX-TV10 also costing US$500. The Panasonic WG-R2 was slightly more affordable at US$450.

In 1999, Kyocera released the VP-210 VisualPhone, the world's first mobile color videophone that doubled as a camera phone for still photos. It had a large camera lens and a 5 cm color TFT display capable of displaying 65,000 colors.

The VP-210 was a groundbreaking device that sent two images per second through Japan's PHS mobile phone network system. Its camera was a 110,000-pixel front-facing camera that could take 20 photos and convey them by email.

The Kyocera project was initiated by Kazumi Saburi, a section manager at their Yokohama research and development center. He envisioned a device that would make cell phone communications more convenient and enjoyable by allowing users to see each other's faces on the display.

The VP-210 was commercially successful, spawning several other competitors such as the DDI Pocket and one from Vodafone K.K.

In 2002, the US Federal Communications Commission authorized sponsored video relay services for the deaf, leading to rapid growth in video relay services in the country.

On a similar theme: Over-the-top Media Services in India

High-speed internet became widely available around the same time, making it easier for people to use video conferencing technology.

The first public demonstration of "true broadband" videoconferencing took place in May 2002, linking a Boeing 737 business jet flying 37,000 feet above Arizona with participants at Boeing's annual investors' conference in St. Louis via satellite at a speed of 256 kilobits per second.

Business videoconferencing systems, which employ video cameras, compression and decompression hardware and software, and interfaces to ISDN lines or an internet connection, began to be widely used in conference rooms to facilitate meetings without travel.

Desktop videophones, which consist of inexpensive cameras connected to a personal computer, video-sharing software, and an internet connection, also became popular, but were typically of lower quality due to bandwidth limitations.

The VP-100 model stand-alone videophone, developed by Sorenson Media Inc. in 2003, was specifically designed for the deaf community and offered remote control and a powerful video compression codec for high-quality video.

Early videophones were a thing long before you could video chat with your friends on your smartphone. The first public demonstration of a one-way videophone occurred on April 7, 1927, between Herbert Hoover and officials of the American Telephone & Telegraph Company (AT&T) in New York City.

The first public demonstration of a two-way videophone took place on April 9, 1930, between AT&T's Bell Laboratories and its corporate headquarters, both in New York City. This two-way system employed early television equipment and a closed circuit.

By 1956, Bell Labs had developed a videophone that could be employed over existing telephone circuits. Further studies led to the development of the first complete experimental videophone system, known as Picturephone, in 1963.

The Picturephone system was a significant improvement over earlier systems, but it still had some limitations. For example, the video bandwidth was 1 MHz with a vertical scan rate of 30 Hz, horizontal scan rate of 8 kHz, and about 250 visible scan lines.

Related reading: Alexander Graham Bell Important Facts

Here's a breakdown of the Picturephone's technical specifications:

The Picturephone system used three twisted pairs of ordinary telephone cable, two pairs for video and one for audio and signaling. Cable amplifiers were spaced about a mile apart with built-in six-band adjustable equalization filters.

The VideoPhone 2500, introduced by AT&T in 1992, was the world's first colour videophone that could transmit over analog telephone lines. It employed digital compression methods to enable a significant reduction of the bandwidth required for full-motion video transmission.

A V.34 modem was used to transmit the compressed video signal over an analog telephone line for access to the PSTN. The video compression algorithm was licensed to several Japanese manufacturers for use in similar videophones.

The VideoPhone 2500 transmitted at either 19.2 or 16.8 kilobits per second, depending on the quality of the telephone line. This was a significant improvement over earlier videophone systems, which were often plagued by poor video quality.

Other manufacturers, such as British Telecommunications and the Marconi Company, developed similar videophone terminals for operation over the PSTN. However, lack of sales led AT&T to discontinue the VideoPhone 2500 in 1995.

Broaden your view: Why Was the Telephone Important in 1876

Videoconferencing allows for real-time communication with people anywhere in the world. It can take place over high-speed internet connections, LAN, or ISDN lines. A video phone is a telephone system with a video display that can play both audio and video simultaneously.

Business videoconferencing systems, installed in conference rooms, provide capture, transmission, and display of synchronized voice and video to one or more locations. They typically use standards developed by the International Telecommunication Union (ITU) for interoperability. Desktop videophones, connected to personal computers, use video-sharing software and an internet connection for lower-quality video calls.

Desktop conferencing software often includes features like application-sharing, a shared clipboard, file-transfer capability, a "whiteboard" for sharing ideas, and chat service between users.

The first video conferencing service was launched in 1970 by AT&T, marking a significant milestone in the development of remote communication. This service was based on the "Mod II" Picturephone, which was refined in the late 1960s.

The inaugural video call took place on June 30, 1970, between Pittsburgh Mayor Peter Flaherty and John Harper of Alcoa. This call was a historic moment that paved the way for future video conferencing technology.

The service officially launched on July 1, 1970, with 38 Picturephones installed at eight Pittsburgh companies. Westinghouse Electric Corporation became one of the largest customers, leasing 12 Picturephone sets.

The service expanded rapidly, with Picturephone service introduced in central Chicago and the suburb of Oak Brook in the following year.

Videoconferencing has come a long way since its inception in 1970 when AT&T launched the first true video conferencing service, with the inaugural video call occurring on June 30, 1970, between Pittsburgh Mayor Peter Flaherty and Chairman and CEO John Harper of Alcoa.

The technology has evolved significantly since then, with business videoconferencing systems employing video cameras, video compression and decompression hardware and software, and interfaces to one or more ISDN lines or an Internet connection to provide capture, transmission, and display of synchronized voice and video to one or more locations.

Desktop videophones, on the other hand, usually consist of inexpensive cameras connected to a personal computer, video-sharing software, and an Internet connection between two PCs, allowing for lower-cost, lower-quality video conferencing.

Business videoconferencing systems are typically installed in conference rooms to permit meetings to be held without requiring travel by the participants, making it a convenient option for remote meetings.

The first public demonstration of “true broadband” videoconferencing between an airplane and the ground occurred in May of 2002, when Boeing announced the first public demonstration of “true broadband” videoconferencing between a Boeing 737 business jet and the ground.

This technology has made it possible for companies to expand and achieve a more global reach, allowing them to speak with clients and team members located across the world, not having to have everyone in the same room at the same time.

Videoconferencing has also made live events possible, such as team-building activities, celebrations, and other important company events, making it easier to connect with people remotely.

Take a look at this: History of the National Broadband Network

Video telephony offers numerous benefits that can enhance your communication and productivity. It can be one of the best ways to communicate for a company or a private individual, as it provides a more engaging and efficient way to interact.

Video conferencing engages people more than normal telephone calls, making it easier to feel understood and improving both sides of the conversation. People tend to feel they are better understood if they can see one another, and interpersonal cues, like eye contact, can improve the conversation.

Videotelephony makes it less necessary for people to commute, saving time that can be put back into work. A video conference is also more efficient than an email, allowing for real-time interaction and screen sharing.

Humans process visual information much more quickly than audio or text, making visual communication up to 60,000 times faster. Information retention is also much higher when using visual communication, making each meeting more productive.

Video conferencing allows companies to expand and achieve a more global reach, without the need for physical branches in other countries. It's not always easy to get everyone in the same room, but videotelephony offers more flexibility, helping boost attendance.

Being able to see and speak with the person providing a service or product is important for clients, making them feel more confident in the services the company provides. This can lead to improved client relationships and a more positive experience.

Businesses that rely on VoIP for communication are increasingly vulnerable to cybersecurity attacks. Cybercriminals are exploiting vulnerabilities in VoIP systems, leading to crippling financial losses.

In South Africa, businesses are particularly at risk due to the growing reliance on VoIP for cost-effective and flexible communication. Without robust cyber security measures, businesses risk losing control over their communications.

Cybersecurity attacks on VoIP systems can result in devastating data breaches and complete operational shutdowns.

The cost of videotelephone service was quite steep in the early days. Companies were charged $150 for the first set installation.

In 2012 dollars, the monthly service fee for the first set was $947, with an additional $50 per month for each additional set. This made videotelephone service a significant expense for businesses.

Extra minutes beyond the included 30 minutes or 45 minutes, depending on the plan, cost 25 cents.

In the United Kingdom, the first commercial videophone, the British Telecom Relate 2000, was released in 1993 for a price of between £400-£500 each.

The Relate 2000 had a 74 millimetres (2.9 in) flip-up colour LCD display screen that operated at a nominal rate of 8 video frames per second.

Its video quality was generally poor due to the limited bandwidth of British phone lines, which provided less than 3.4 kHz of bandwidth.

British Telecom had expected the device to sell at a rate of 10,000 per year, but its actual sales were minimal.

Downtime isn't just an inconvenience, it's a potential crisis. Productivity halts, employees are disconnected, customers are left frustrated, and revenue streams dry up.

Staying connected is crucial for businesses, and downtime can have severe consequences. In a world where communication is instant and operations are largely digital, business connectivity solutions form the backbone of efficiency.

Downtime can lead to lost revenue streams, and it's not just about the immediate impact. The longer a business is down, the more it can affect its reputation and customer loyalty.

High-availability telecom solutions can help prevent disruptions, and they're tailored to meet the unique needs of businesses.

Service pricing varied depending on the number of Picturephone sets a company had. The installation charge for the first set was $150. Companies paid $160 per month, or $947/month in 2012 dollars, for the service on the first set. This monthly fee included 30 minutes of video calling. Extra minutes beyond that cost 25 cents each. AT&T later reduced the price to $75 per month, which included 45 minutes of video calling.

The development of videotelephone technology involved the contributions of many inventors and companies.

One of the earliest videotelephone patents was granted to Jerome H. Lemelson in 1984 for a "Video telephone" (US4485400A).

Several companies, including Compression Labs, Inc. and Picturetel Corporation, also developed videotelephone technology in the 1980s.

Compression Labs, Inc. patented a "Digital video compression system and methods utilizing scene adaptive coding with rate buffer feedback" in 1981 (US4302775A).

Picturetel Corporation developed a method and apparatus for efficiently communicating image sequences in 1987 (US4703350A).

The company also improved motion compensation in image sequences in 1988 (US4727422A).

Eude Gerard developed a hybrid coding process by transformation for the transmission of picture signals in 1989 (US4827338A).

Compression Labs, Inc. combined intraframe and interframe transform coding in 1987 (US4704628A).

The USA Video Inc. patented a store and forward video system in 1992 (US5130792A).

Alkanox Corporation and Sony Corporation also developed videotelephone technology in the 1990s.

Here is a list of some of the key videotelephone patents:
