convert pfx to pem with openssl command

Author

Reads 904

Close-up of a handshake exchanging keys in an office setting.
Credit: pexels.com, Close-up of a handshake exchanging keys in an office setting.

You can convert a PFX file to a PEM file using the OpenSSL command, and it's a straightforward process.

The OpenSSL command to convert a PFX file to a PEM file is: openssl pkcs12 -in input.pfx -out output.pem.

This command will extract the private key and certificate from the PFX file and save them as a single PEM file.

To specify the password for the PFX file, you can add the -passin option, for example: openssl pkcs12 -in input.pfx -passin pass:your_password -out output.pem.

Additional reading: Cannot Load Such File Openssl

What is PKCS #12?

PKCS #12 is an archive file format used for storing multiple cryptography objects in a single file.

The filename extension for PKCS #12 files is .p12 or .pfx. This format is often used to bundle a PEM certificate and its corresponding private key, along with any additional CA chain certificates.

PKCS #12 files are typically used to store server certificates, intermediate certificates, and private keys in one encryptable file.

That Is Locked

Credit: youtube.com, Explaining Keystores | Part 3 - PKCS#12

You can extract a private key from a PFX file, but it's recommended to combine the password argument with the conversion in one command to avoid errors. This is especially important if your PFX file is locked with a password.

The command for extracting the private key is: openssl pkcs12 -in your.pfx -nocerts -nodes | openssl rsa -out private.key

You can also extract the public key, but be aware that the downside of doing it this way is that your password will be in your command history. To avoid this, you can run unset HISTFILE and the history won't be saved from the current session.

Here are the commands for extracting the public key and the CA chain:

  • Extract public pem (no MS Bag Attributes): openssl pkcs12 -in your.pfx -clcerts -nokeys | openssl x509 -out pub.pem
  • Extract the CA chain (if present) (no MS Bag Attributes): openssl pkcs12 -in your.pfx -cacerts -nokeys | openssl x509 -out somechain.crt

If you need to password-protect the private key during export, you can use the command: openssl rsa -in private.key -aes256 -out private-secure.key

A fresh viewpoint: Openssl Cert Key

PKCS#12 Format

The PKCS#12 format is a binary format for storing the server certificate, any intermediate certificates, and the private key in one encryptable file. PFX files usually have extensions such as .pfx and .p12.

For another approach, see: Create Pfx from Crt and Key Openssl

Credit: youtube.com, P12 - Public-Key Cryptography Standards (PKCS) #12

PFX files are typically used on Windows machines to import and export certificates and private keys. This format is often used to bundle a PEM certificate and its corresponding private key, along with any additional CA chain certificates.

A PFX file can be converted to PEM format using OpenSSL, which will put all the certificates and the private key into a single file. You will need to open the file in a text editor and copy each certificate and private key (including the BEGIN/END statements) to its own individual text file and save them as certificate.cer, CACert.cer, and privateKey.key respectively.

Here's a step-by-step guide on how to extract a clean private key from a PFX file:

  • Use the command `openssl pkcs12 -in your.pfx -nocerts -nodes | openssl rsa -out private.key` to extract the private key.
  • Use the command `openssl pkcs12 -in your.pfx -clcerts -nokeys | openssl x509 -out pub.crt` to extract the public key.
  • Use the command `openssl pkcs12 -in your.pfx -clcerts -nokeys | openssl x509 -out pub.pem` to extract the public PEM.
  • Use the command `openssl pkcs12 -in your.pfx -cacerts -nokeys | openssl x509 -out somechain.crt` to extract the CA chain (if present).

Remember to password-protect the private key during export if necessary. If your certificate has a password, you must provide it on your OpenSSL command using the `--passin pass:xxxxx` argument.

Converting File Formats

You can convert a PFX file to PEM format using OpenSSL, a free and open-source toolkit that implements SSL and TLS protocols.

Credit: youtube.com, Convert pfx Certificates to pem with OpenSSL

The PEM format is the most common format that Certificate Authorities issue certificates in, and it's usually used by servers like Apache.

To convert a PFX file to PEM, you can use the OpenSSL command line tool, which is available on Linux and Unix systems.

The OpenSSL command line tool can convert a PFX file to a PEM file containing a certificate as well as a private key.

You can also convert a PFX file to separate PEM files for the certificate and key, which is useful for web servers like Nginx/Apache.

Here are the steps to convert a PFX file to separate PEM files:

  • Use the OpenSSL command to extract the certificate from the PFX file: `openssl pkcs12 -in filename.pfx -clcerts -nokeys -out cert.pem`
  • Use the OpenSSL command to extract the private key from the PFX file: `openssl pkcs12 -in filename.pfx -nocerts -nodes -out key.pem`

The resulting PEM files can be used on web servers like Nginx/Apache.

You can also concatenate the key and certificate into a single PEM file using the OpenSSL command: `cat key.pem cert.pem > combined.pem`

Readers also liked: P7b to Pem

Credit: youtube.com, How to Convert PFX to PEM Using OpenSSL 3.1.4 on Windows Server 2022

The resulting combined PEM file can be used on web servers like Nginx/Apache.

Note: Make sure to remove any passphrase from the private key before using it on web servers like Nginx/Apache.

Here are the OpenSSL commands to remove a passphrase from the private key:

  • On Windows: `openssl rsa -in key.pem -out key-without-passphrase.pem`
  • On Linux: `openssl rsa -in key.pem -out key-without-passphrase.pem`

The resulting PEM file without a passphrase can be used on web servers like Nginx/Apache.

OpenSSL Commands

You can use OpenSSL commands to convert SSL certificates on your own machine, keeping the private key there for security.

The command `openssl pkcs12 -in certificatepfx.pfx -nocerts -out privatekeyconvert.pem -nodes` exports the private key from a PFX file.

To export a certificate from a PFX file, use the command `openssl pkcs12 -in certificatepfx.pfx -clcerts -nokeys -out certconvert.pem`.

You can also use the command `openssl pkcs12 -in certificatepfx.pfx -out convertcert.pem -nodes` to convert a PFX file to a PEM file containing a certificate and private key.

It's recommended to convert to and from .pfx files on your own machine using OpenSSL.

Credit: youtube.com, Convert PFX to PEM Using OpenSSL 3.1.4 on Windows Server 2022

To convert a PFX file to a PEM file containing a certificate as well as a private key, use the following commands:

  • `openssl pkcs12 -in certificate.pfx -nocerts -nodes -out privatekey.pem`
  • `openssl pkcs12 -in certificate.pfx -clcerts -nokeys -out cert.pem`

You can also remove the passphrase from the private key using the command `openssl rsa -in privatekey.pem -out privatekey-without-passphrase.pem`.

To concatenate the key and certificate, use the command `cat privatekey.pem cert.pem > combined.pem`.

Here's a summary of the OpenSSL commands for converting PFX to PEM:
