Designing and Measuring with Harmonic Mixers

Harmonic mixers are a crucial tool for engineers and researchers, allowing them to measure and analyze complex signals with high accuracy.

A harmonic mixer is essentially a device that combines two signals, one of which is a local oscillator, to produce a signal that is a combination of the two.

This process is called mixing, and it's a fundamental concept in signal processing. Harmonic mixers can be used to measure the frequency and amplitude of signals, which is essential in various fields such as telecommunications, radar, and spectroscopy.

The output of a harmonic mixer can be used to measure the power and frequency of a signal, which is critical in applications where signal integrity is paramount.

Related reading: Which Motor Is Used in Mixer?

A harmonic mixer is a type of mixer that uses a nonlinear device, such as a crystal diode, to generate harmonics of a standard low-frequency signal. These harmonics are then heterodyne with a microwave test signal to produce an IF signal.

Discover more: Mobile Phone Signal

Harmonic mixers are particularly useful in frequency calibration setups, where they can be used to generate a wide range of frequencies. They're also used in applications where signal levels are significant compared to noise power.

The harmonic amplitude or power is inversely proportional to the harmonic order, which means that higher-order harmonics have lower power levels. This is important to keep in mind when designing harmonic mixer circuits.

Here are some examples of harmonic mixers and their frequency ranges:

The LO frequency range for these harmonic mixers is typically 2 GHz to 20 GHz.

A harmonic mixer is a type of mixer that uses a nonlinear device, such as a crystal diode, to generate harmonics of a standard low-frequency signal. These harmonics are then heterodyne with a microwave test signal to produce an IF signal.

The harmonic mixer circuit operation is based on the interaction between the Local Oscillator (LO) signal and the incoming Radio Frequency (RF) signal. The LO signal generates currents within the crystal, which contain the fundamental frequency and its harmonics.

Recommended read: Signal Strength in Telecommunications

The RF signal interacts with these frequencies, resulting in sum and difference frequency components. The IF amplifier is tuned to extract the difference frequency component.

A harmonic mixer utilizes a harmonic of the LO signal along with the low-frequency LO to generate the IF frequency. The conversion loss of a harmonic mixer is defined as: Conversion Loss (dB) = 10 * Log10 (IF output power / RF input power).

A harmonic mixer's harmonic amplitude or power is inversely proportional to the harmonic order. This means that the higher the harmonic order, the lower the power of the harmonic.

Here's a summary of the harmonic mixer's frequency ranges and LO frequency ranges:

A harmonic mixer's design is surprisingly straightforward, often using a step recovery diode (SRD) to amplify the subharmonic input to a power level of around 1 watt.

The SRD then drives an impulse generator circuit, turning the sine wave into an impulse train with harmonics up to 18 GHz. This impulse train is then used with a diode mixer, also known as a sampler.

The SRD has a very high frequency multiplication ratio, making it suitable for comb receivers that can monitor several harmonically related frequencies at once. This is the basis for many simple 'bug detectors' that can detect transmission on any frequency, even if not known in advance.

For lower frequency multiples, such as doubling or tripling, Schottky diode circuits are more common, allowing for adjustment of the conduction angle by changing drive level or temperature.

Related reading: Critical Frequency

A harmonic mixer can be a simple and reliable frequency extender to a low frequency design.

One classic design for a harmonic mixer uses a step recovery diode (SRD) to amplify the subharmonic input to a power level around 1 watt.

The SRD usually has a very high frequency multiplication ratio, and can be used as the basis of a comb receiver, monitoring several harmonically related frequencies at once.

This design forms the basis of many simple 'bug detectors' where the intention is to detect transmission on any frequency, even if not known in advance.

For your interest: Rf Frequency Mixer

Schottky diode circuits are more common for lower frequency multiples, such as doubling, tripling or quadrupling.

The conduction angle can be adjusted by changing drive level or temperature, and determines which part of the I/V curve is used and therefore the relative strengths of the different harmonically related outputs.

A harmonic mixer can suppress the odd local oscillator contribution if an even multiple is desired, by using an anti-parallel pair of diodes.

Unlike a normal mixer, there is a fairly clear optimum drive level, above which the conversion loss increases.

Modern spectrum analyzers can compensate for external harmonic mixer attributes, providing accurate amplitude and frequency readouts. This is especially convenient for users who want to simplify their measurement process.

To achieve accurate amplitude readouts, you'll need to apply the typical amplitude correction factor, also known as conversion loss, supplied by the harmonic mixer manufacturer. This value is influenced by the nth harmonic of the LO signal needed to down-convert the RF to the predefined IF for signal analysis.

The conversion loss increases with higher multiplier values, as shown in Figure 4, which represents the conversion loss of a single diode, unbalanced harmonic mixer versus the mm-wave frequency range for the Agilent PSA Signal Analyzer (model E444xA). This is a typical result for the predefined LO, IF capabilities of the PSA.

For simplified frequency readouts, the spectrum analyzer contains preset settings, selectable by waveguide band, to compensate for the multiplication factor. This allows the frequency scale to read RF instead of LO or IF.

To independently verify the operation of the harmonic mixer, you'll need a mm-wave source with a known power level. Simply set the RF source to a value in the harmonic mixer's linear range, avoiding input compression.

Using Figure 1, apply the "reference" RF signal to the input of the harmonic mixer and complete the LO and IF connections to the spectrum analyzer. An external diplexer may be necessary for this setup.

After properly configuring the spectrum analyzer for external mixer operation, the readout will display a measured value that includes the reference signal level and the harmonic mixer's conversion loss.

Explore further: Tuned Radio Frequency Receiver
